Push-in L-fitting M5 to tubing OD 6 mm, PVDF NPQO-L-M5-Q6-P10 - Festo 8203303

Festo ✓ Original product Brand new

The push-in L-fitting NPQO-L-M5-Q6-P10 routes tubing with an OD of 6 mm away from the M5 thread at an angle. Operating limits: -0.9 to 3 bar and 0 to 60 °C. The housing is made of PVDF, corrosion resistance class CRC 2.

Net
€14.10
excl. VAT
Item FES-8203303
Manufacturer no. NPQO-L-M5-Q6-P10
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The push-in L-fitting NPQO-L-M5-Q6-P10 routes tubing with an OD of 6 mm away from the M5 thread at an angle. Operating limits: -0.9 to 3 bar and 0 to 60 °C.

Benefits

  • From vacuum up to 3 bar operating pressure -0.9 to 3 bar across the full temperature range
  • Biocompatible to ISO 18562
  • Nominal width 2.6 mm
  • Nominal tightening torque 2.25 Nm (± 10 %)
  • Up to 16 bar depending on temperature
  • Ambient temperature 0 to 60 °Cmedium temperature 0 to 120 °C

Applications

Typical locations for the NPQO-L-M5-Q6-P10 are valves, cylinders and service units with a M5 port. The NPQO-L-M5-Q6-P10 works with compressed air to ISO 8573-1:2010 [7:4:4], inert gases, carbon dioxide, air, oxygen, nitrogen..

Technical data

FeatureValue
TypeNPQO-L-M5-Q6-P10
Festo part number8203303
Nominal width2.6 mm
Tubing insertion depth15.6 mm
Seal type on screw-in studO-ring
Mounting positionAny
DesignL-shape
ConstructionPush-pull principle
VariantsWith mounting holes
Operating pressure, full temperature range-0.9 to 3 bar
Temperature-dependent operating pressure-0.9 to 16 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:4:4], inert gases, carbon dioxide, air, oxygen, nitrogen
Corrosion resistance class CRC2 - moderate corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Food suitabilitySee extended material information
Medium temperature0 to 120 °C
Ambient temperature0 to 60 °C
Biocompatibility to standardISO 18562
Oxygen suitability to standardASTM G 93, ISO 15001
Max. hydrocarbon contamination level550 mg/m²
Max. tightening torque2.5 Nm
Nominal tightening torque2.25 Nm
Tolerance of nominal tightening torque± 10 %
Product weight13.22 g
Pneumatic connection 1Male thread M5
Pneumatic connection 2For tubing OD 6 mm
Release ring colourWhite
Screw-in stud materialHigh-alloy stainless steel
Material noteRoHS compliant
Housing materialPVDF
Thread seal materialFPM
Release ring materialPVDF
O-ring materialFPM
Tubing seal materialFPM
Tubing clamp segment materialHigh-alloy stainless steel
Support ring materialPVDF
Weight0.014 kg
ManufacturerFesto
Hersteller-NrNPQO-L-M5-Q6-P10
EAN4052568659356
Zolltarifnummer73072910
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPVDF
BauformL-Form
ThreadM5
For hose OD [mm]6
Nominal size DN [mm]2,6
Seal materialFPM
MediumCompressed air
Thread typeExternal thread
Medientemperatur [°C]0 bis 120
Betriebsdruck max [bar]3
Temperaturbereich0-60 °C
Temperature (max.)60
