Straight push-in connector for tubing OD 6 mm, PBT NPQE-D-Q6-E-F1A-P10 - Festo 8158789

Festo ✓ Original product Brand new

The NPQE-D-Q6-E-F1A-P10 push-in connector extends tubing lines with an OD of 6 mm or rejoins them after damage. The NPQE-D-Q6-E-F1A-P10 is specified for -0.95 to 8 bar operating pressure and -5 to 60 °C ambient temperature.

Net
€3.74
excl. VAT
Item FES-8158789
Manufacturer no. NPQE-D-Q6-E-F1A-P10
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The NPQE-D-Q6-E-F1A-P10 push-in connector extends tubing lines with an OD of 6 mm or rejoins them after damage. The NPQE-D-Q6-E-F1A-P10 is specified for -0.95 to 8 bar operating pressure and -5 to 60 °C ambient temperature.

Benefits

  • From vacuum up to 8 bar operating pressure -0.95 to 8 bar across the full temperature range
  • LABS (PWIS) conformity to VDMA24364 zone III
  • Cleanroom suitable class 4 to ISO 14644-1
  • Battery production reduced Cu/Zn/Ni content to F1a
  • Nominal width 4 mm
  • Mini sizeproduct weight 1.87 g

Applications

NPQE-D-Q6-E-F1A-P10 is used to extend and repair tubing lines with an OD of 6 mm. The NPQE-D-Q6-E-F1A-P10 works with compressed air to ISO 8573-1:2010 [7:4:4], lubricated operation possible..

Technical data

FeatureValue
TypeNPQE-D-Q6-E-F1A-P10
Festo part number8158789
SizeMini
Nominal width4 mm
Mounting positionAny
DesignStraight
ConstructionPush-pull principle
Operating pressure, full temperature range-0.95 to 8 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Suitability for Li-ion battery productionSuitable for battery production with reduced Cu/Zn/Ni content (F1a)
Cleanroom suitability, measured to ISO 14644-14Class 4 to ISO 14644-1
Ambient temperature-5 to 60 °C
Product weight1.87 g
Pneumatic connection 1For tubing OD 6 mm
Pneumatic connection 2For tubing OD 6 mm
Release ring colourBlue
Material noteRoHS compliant
Housing materialPBT
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialHigh-alloy stainless steel
Weight0.002 kg
ManufacturerFesto
Hersteller-NrNPQE-D-Q6-E-F1A-P10
EAN4052568599164
Zolltarifnummer39174000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
Bauformgerade Form
For hose OD [mm]6
Nominal size DN [mm]4
Size BGMini
Seal materialNBR
MediumCompressed air
Betriebsdruck max [bar]8
Temperaturbereich-5-60 °C
Temperature (max.)60
