Coupling sleeve M5 on both ends made of nickel-plated brass NPFC-S-2M5-F - Festo 8030290
The NPFC-S-2M5-F coupling sleeve screws two threaded parts of the same size together. Both ends carry M5. Pressure range NPFC-S-2M5-F: -0.95 to 50 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The NPFC-S-2M5-F coupling sleeve screws two threaded parts of the same size together. Pressure range NPFC-S-2M5-F: -0.95 to 50 bar.
Benefits
- Operating pressure -0.95 to 50 bar, vacuum-capable
- Ambient temperature -20 to 150 °C
- Threaded fitting made of nickel-plated brass
- Corrosion resistance class CRC 1 for low corrosion stress
- PWIS (LABS) conformity to VDMA24364-B1/B2-L
Applications
For extensions and connections in compressed-air lines and on devices.
Technical data
| Feature | Value |
|---|---|
| Type | NPFC-S-2M5-F |
| Festo part number | 8030290 |
| Threaded fitting material | Nickel-plated brass |
| Operating pressure | -0.95 to 50 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [-:-:-] |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| PWIS (LABS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20 to 150 °C |
| Pneumatic connection 1 | M5 |
| Pneumatic connection 2 | M5 |
| Material note | RoHS compliant |
| Manufacturer | Festo |
| Hersteller-Nr | NPFC-S-2M5-F |
| EAN | 4052568063924 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Nickel-plated brass |
| Thread | M 5 |
| Thread 2 | M5 |
| Medium | Compressed air |
| Betriebsdruck max [bar] | 50 |
| Pneumatic connection | M5 |
| Temperaturbereich | -20-150 °C |
| Temperature (max.) | 150 |
