Nipple for couplings DN 5, nickel-plated brass, with union nut and kink protection spring, hose connection 6 x 4 mm, 8 x 6 mm, up to 35 bar - Riegler
This nipple DN 5 made of nickel-plated brass is the mating part for the coupling, connection hose connection 6 x 4 mm, 8 x 6 mm. Ratings nipple DN 5, nickel-plated brass: operating pressure 0 to 35 bar, medium and ambient temperature -20 to 100 °C, with union nut and kink protection spring. Select thread and size in the variant selection.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
This nipple DN 5 made of nickel-plated brass is the mating part for the coupling, connection hose connection 6 x 4 mm, 8 x 6 mm.
Ratings nipple DN 5, nickel-plated brass: operating pressure 0 to 35 bar, medium and ambient temperature -20 to 100 °C, with union nut and kink protection spring.
Benefits
- Fits couplings DN 5
- Hose connection 6 x 4 mm, 8 x 6 mm
- Nickel-plated brass, with union nut and kink protection spring
- Operating pressure 0 to 35 bar, -20 to 100 °C
Applications
- Compressed air lines with couplings DN 5
- Connecting air tools and consumers to couplings
Technical data
| Fits couplings | DN 5 |
|---|---|
| Material | nickel-plated brass |
| Version | with union nut and kink protection spring |
| Length | 110 to 120 mm |
| Width across flats | 12 to 14 mm |
| Operating pressure | 0 to 35 bar |
| Medium and ambient temperature | -20 to 100 °C |
| Manufacturer | Riegler |
| GPSR Herstellerdaten | Riegler & Co. KG, Schützenstraße 27, DE-72574 Bad Urach, www.riegler.de |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
