Nipple ISO 6150 C 5.5 mm, male thread R 1/4", 1090 l/min - Cejn 102915152

Nipple 102915152 is the plug-in half of a compressed air quick coupling. It is fitted with male thread R 1/4" and passes 1090 l/min once coupled.

Benefits

• Low pressure drop in the plug-in area, matching the air flow of 1090 l/min.
• Version with male thread R 1/4".
• Net weight 0.02 kg.
• Air flow 1090 l/min at a working pressure of up to 12 bar.
• Nipple profile ISO 6150 C 5.5 mm, interchangeable with existing couplings of the same standard.

Applications

The part is used in workshop and production air distribution, on polyurethane hose lines and on FRL units and hand tools.

Standards and marking

Manufacturer marking: ISO 6150 C. Nipple profile as stated by the manufacturer: ISO 6150 C 5.5 mm.
