Nipple ISO 6150 B 11 mm, male thread NPT 1/4", 4050 l/min, steel - Cejn 105505452

The nipple is the counterpart to the coupling. It is connected with male thread NPT 1/4", passes 4050 l/min and withstands a working pressure of up to 16 bar.

Benefits

• Air flow 4050 l/min at a working pressure of up to 16 bar.
• Nipple profile ISO 6150 B 11 mm, interchangeable with existing couplings of the same standard.
• Low pressure drop in the plug-in area, matching the air flow of 4050 l/min.
• Body made of steel.
• Version with male thread NPT 1/4".
• Soft-Line design as marked by the manufacturer.

Applications

The part is used in workshop and production air distribution, on polyurethane hose lines and on FRL units and hand tools.

Standards and marking

Manufacturer marking: ISO 6150 B, A-A 59439. Nipple profile as stated by the manufacturer: ISO 6150 B A-A-59439 11 mm. It also carries the manufacturer marking Soft-Line.
