Nipple, female thread, G 1/8" (BSP), DN 5, 720 bar, steel - Cejn 101656201

The nipple is the counterpart to the flat-face coupling and carries the female thread G 1/8" (BSP) at 720 bar working pressure.

Benefits

• Max. working pressure coupled 720 bar, minimum burst pressure 1440 bar.
• Body size DN 5 matching the nominal size 1/8".
• Main material Steel with seals made of NBR.
• Connection G 1/8" (BSP) in female thread version.

Applications

Typical applications are hydraulic circuits up to 720 bar where tools, cylinders or power units are changed and the connection is made by hand.

Standards and conformity

The body size follows the ISO 16028 standard for flat-face hydraulic couplings. The manufacturer lists this body size as series 165. Manufacturer marking: X65. Main material Steel, seal material NBR.
