Nipple, female thread, G 1/4", DN 6.3, 500 bar, steel - Cejn 102656212

Name: Nipple, female thread, G 1/4", DN 6.3, 500 bar, steel - Cejn 102656212
Brand: Cejn
SKU: CEJ-102656212
Price: 14.42 EUR
Availability: InStock

Cejn ✓ Original product Brand new

Nipple DN 6.3 is screwed on through G 1/4" and is rated for 500 bar when coupled. Material steel with FPM seals. The flat-face design to ISO 16028 limits spillage when the line is parted.

Net

€14.42

excl. VAT

Item CEJ-102656212

Manufacturer no. 102656212

Question about this item

Datasheet (PDF) 2 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Nipple DN 6.3 is screwed on through G 1/4" and is rated for 500 bar when coupled.

Benefits

Body size DN 6.3 matching the nominal size 1/4".
Main material Steel with seals made of FPM.
Connection G 1/4" in female thread version.
Dust caps for coupling and nipple are available as accessories.

Applications

Typical applications are hydraulic circuits up to 500 bar where tools, cylinders or power units are changed and the connection is made by hand.

Standards and conformity

The body size follows the ISO 16028 standard for flat-face hydraulic couplings. The manufacturer lists this body size as series 265. Manufacturer marking: X65. Main material Steel, seal material FPM.

Technical data

Type	Nipple
Version	Female thread
Body size ISO-DN	6.3
Size in inches	1/4"
Connection type	Flat-face quick couplings
Connection	G 1/4"
Max. working pressure coupled	500 bar
Min. burst pressure coupled	1500 bar
Main material	Steel
Seal material	FPM
Weight	0.085 kg
Packaging unit	1 piece
Manufacturer	Cejn
Hersteller-Nr	102656212
Zolltarifnummer	84812010
GPSR Herstellerdaten	CEJN-Product GmbH, Junkersring 16, DE-53844 Troisdorf, www.cejn.com
Artikelzustand	New
Artikel-Authentizität	Original product
