End plate kit up to 16 bar, PWIS-free NEV-3DA/DB-NPT - Festo 13997
The end plate kit NEV-3DA/DB-NPT forms the end of a valve manifold. Port 1 as NPT1-11 1/2, operating pressure 0 to 16 bar. Weight 0.75 kg.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The end plate kit NEV-3DA/DB-NPT forms the end of a valve manifold. Lines connect via port 1 as NPT1-11 1/2, port 3 as NPT1-11 1/2 and port 5 as NPT1-11 1/2. The NEV-3DA/DB-NPT operates at 0 to 16 bar.
Benefits
- Pressure range: 0 to 16 bar
- PWIS-free: VDMA 24364-B1/B2-L
- Ambient temperature: -10 to 60 °C
Applications
The NEV-3DA/DB-NPT is mounted with through-hole. The valve is attached screw-in. Operating medium: compressed air to ISO 8573-1:2010 [7:-:-], lubricated operation possible (in which case lubricated operation will always be required). Ambient and medium temperature -10 to 60 °C each.
Technical data
| Type | NEV-3DA/DB-NPT |
|---|---|
| Festo part number | 13997 |
| Width | 190 mm |
| Operating pressure | 0 to 16 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Medium temperature | -10 to 60 °C |
| Ambient temperature | -10 to 60 °C |
| Mounting type sub-base | With through-hole |
| Mounting type valve | Screw-in |
| Pneumatic connection, port 1 | NPT1-11 1/2 |
| Pneumatic connection, port 3 | NPT1-11 1/2 |
| Pneumatic connection, port 5 | NPT1-11 1/2 |
| Weight | 0.75 kg |
| Manufacturer | Festo |
| Hersteller-Nr | NEV-3DA/DB-NPT |
| EAN | 4052568304355 |
| Zolltarifnummer | 84819000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Medium | Compressed air |
| Series | NEV |
| Betriebsdruck max [bar] | 16 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
