Connecting cable 2 m, 8-pin M12x1 socket to 4-pin M12x1 plug NEBV-M12G8-K-2-M12G4 - Festo 553575
The connecting cable NEBV-M12G8-K-2-M12G4 runs from M12x1 A-coded socket (8-pin) to M12x1 A-coded plug (4-pin). For fixed installation the bending radius is 29 mm. The TPE-U(PUR) sheath has a diameter of 5.6 mm. Operating voltage 0 to 30 V DC.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo connecting cable NEBV-M12G8-K-2-M12G4 is 2 m long.
Benefits
- Field device side: M12x1 A-coded socket (8-pin), straight
- Control side: M12x1 A-coded plug (4-pin), straight
- Bending radius: 29 mm in fixed installation
- Electrical: 2 A at 40 °C, 0 to 30 V DC
- Cable sheath: TPE-U(PUR), halogen-free, diameter 5.6 mm, shielded
- Environment: IP67, -5 to 80 °C in moving installation
Applications
The halogen-free TPE-U(PUR) sheath is a criterion in plants with fire protection requirements.
Technical data
| Conforms to standard | EN 61076-2-101 |
|---|---|
| Cable designation | Without inscription label holder |
| Electrical connection 1, function | Field device side |
| Electrical connection 1, design | Round |
| Electrical connection 1, connection type | Socket |
| Electrical connection 1, cable outlet | Straight |
| Electrical connection 1, connector system | M12x1, A-coded to EN 61076-2-101 |
| Electrical connection 1, number of connections/cores | 8 |
| Electrical connection 1, used connections/cores | 4 |
| Electrical connection 1, type of mounting | Screw-type lock |
| Electrical connection 2, function | Control side |
| Electrical connection 2, design | Round |
| Electrical connection 2, connection type | Plug |
| Electrical connection 2, cable outlet | Straight |
| Electrical connection 2, connector system | M12x1, A-coded to EN 61076-2-101 |
| Electrical connection 2, number of connections/cores | 4 |
| Electrical connection 2, used connections/cores | 4 |
| Electrical connection 2, type of mounting | Screw-type lock |
| Operational voltage range DC | 0 to 30 V |
| Operational voltage range AC | 0 to 30 V |
| Current rating at 40 °C | 2 A |
| Immunity to surge | 0.8 kV |
| Shielding | Yes |
| Cable length | 2 m |
| Cable characteristic | Standard |
| Bending radius, fixed cable | 29 mm |
| Bending radius, moving cable | 58 mm |
| Cable diameter | 5.6 mm |
| Cable diameter tolerance | ±0.2 mm |
| Cable structure | 4 x 0.34 mm² |
| Nominal cross section conductor | 0.34 mm² |
| Degree of protection | IP67 |
| Note on degree of protection | In mounted state |
| Ambient temperature | -25 to 85 °C |
| Ambient temperature with moving cable | -5 to 80 °C |
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK RoHS instructions |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Note on materials | RoHS compliant, free of halogen |
| Pollution degree | 3 |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| Material cable sheath | TPE-U(PUR) |
| Cable sheath colour | Grey |
| Material housing | TPE-U(PUR) |
| Housing colour | Black |
| Material screw-type lock | Brass, nickel-plated |
| Material seals | NBR |
| Material electrical contact | Gold-plated brass |
| Material insulating sheath | PP |
| Weight | 0.115 kg |
| Manufacturer | Festo |
| Hersteller-Nr | NEBV-M12G8-K-2-M12G4 |
| EAN | 4052568096052 |
| Zolltarifnummer | 85444290 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Colour | Grey |
| Material | TPE-U(PUR) |
| min. Biegeradius [mm] | 29 |
| Norm | DIN EN 61076-2-101 |
| Series | NEBV |
| Protection rating | IP67 |
| Temperature (max.) | 85 |
