Connecting cable 10 m, suitable for robots, M12x1 T-coded socket to open end NEBM-T12G4-R-10-LE4 - Festo 8140937
Connecting cable NEBM-T12G4-R-10-LE4, 10 m long: M12x1 T-coded socket, straight, 4 pins at the field device, open end, 4 cores towards the controller. In moving installation a bending radius of 75 mm is sufficient, the design is suitable for robots. Current rating 5 A at 40 °C, sheath made of PVC.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With a cable length of 10 m and a current rating of 5 A, the connecting cable NEBM-T12G4-R-10-LE4 connects field device and controller.
Benefits
- Field device side: M12x1 T-coded socket, straight, 4 pins
- Control side: open end, 4 cores, stripped
- Suitable for robots: bending radius moving 75 mm, fixed 30 mm
- Electrical: 5 A at 40 °C, 0 to 60 V DC
- Cable sheath: PVC, diameter 7.5 mm
- Environment: IP67, -20 to 80 °C in moving installation
Applications
Festo lists it as an accessory for servo drives. The robot-compatible design is intended for torsion and multi-axis movement on robot arms.
Technical data
| Based on standard | EN 61076-2-111 |
|---|---|
| Cable designation | With inscription label holder |
| Product weight | 800 g |
| Electrical connection 1, function | Field device side |
| Electrical connection 1, design | Round |
| Electrical connection 1, connection type | Socket |
| Electrical connection 1, cable outlet | Straight |
| Electrical connection 1, connector system | M12x1, T-coded according to EN 61076-2-111 |
| Electrical connection 1, number of connections/cores | 4 |
| Electrical connection 1, used connections/cores | 4 |
| Electrical connection 1, type of mounting | Screw-type lock |
| Electrical connection 2, function | Control side |
| Electrical connection 2, connection type | Cable |
| Electrical connection 2, connector system | Open end |
| Electrical connection 2, number of connections/cores | 4 |
| Electrical connection 2, used connections/cores | 4 |
| Operational voltage range DC | 0 to 60 V |
| Current rating at 40° C | 5 A |
| Immunity to surge | 1.5 kV |
| Shielding | No |
| Cable length | 10 m |
| Cable characteristic | Suitable for robot applications |
| Test conditions cable | Test conditions on request |
| Bending radius, fixed cable | 30 mm |
| Bending radius, moving cable | 75 mm |
| Cable diameter | 7.5 mm |
| Cable diameter tolerance | ±0.2 mm |
| Cable structure | 4 x 0.75 mm² |
| Nominal cross section conductor | 0.75 mm², AWG19 |
| Wire ends | Stripped |
| Degree of protection | IP67 |
| Note on degree of protection | In mounted state |
| Ambient temperature | -40 to 80 °C |
| Ambient temperature with moving cable | -20 to 80 °C |
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK RoHS instructions |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Note on materials | RoHS compliant |
| Pollution degree | 3 |
| Corrosion resistance class CRC | 0 - No corrosion stress |
| Material cable sheath | PVC |
| Cable sheath colour | Black |
| Material housing | TPE-U(PUR) |
| Housing colour | Black |
| Material screw-type lock | High-alloy stainless steel |
| Material seals | HNBR |
| Material electrical contact | Gold-plated brass |
| Material insulating sheath | PVC |
| Weight | 0.85 kg |
| Manufacturer | Festo |
| Hersteller-Nr | NEBM-T12G4-R-10-LE4 |
| EAN | 4052568601539 |
| Zolltarifnummer | 85444290 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Colour | Black |
| Material | PVC |
| min. Biegeradius [mm] | 30 |
| Norm | DIN EN 61076-2-111 |
| Series | NEBM |
| Protection rating | IP67 |
| Temperaturbereich | -40-80 °C |
| Temperature (max.) | 80 |
