Encoder cable NEBM-REG6-K-2.5-Q14N-REG6 - Festo 5219209
Net
excl. VAT
€21.53
Item
FES-5219209
Manufacturer no.
NEBM-REG6-K-2.5-Q14N-REG6
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Cable designation | Without inscription label holder |
|---|---|
| Electrical connection 1, function | Field device side |
| Electrical connection 1, design | Square |
| Electrical connection 1, connection type | Socket |
| Electrical connection 1, cable outlet | Straight |
| Electrical connection 1, connector system | Connection pattern RE |
| Electrical connection 1, number of connections/cores | 6 |
| Electrical connection 1, used connections/cores | 6 |
| Electrical connection 1, connection pattern | 00995793 |
| Electrical connection 2, function | Control side |
| Electrical connection 2, design | Square |
| Electrical connection 2, connection type | Plug |
| Electrical connection 2, cable outlet | Straight |
| Electrical connection 2, connector system | Connection pattern RE |
| Electrical connection 2, number of connections/cores | 6 |
| Electrical connection 2, used connections/cores | 6 |
| Electrical connection 2, connection pattern | 00995792 |
| Operational voltage range DC | 0 ... 30 V |
| Operational voltage range AC | 0 ... 30 V |
| Current rating at 40° C | 1.6 A |
| Immunity to surge | 2 kV |
| Cable length | 2.5 m |
| Cable characteristic | Standard |
| Test conditions cable | Test conditions on request |
| Bending radius, fixed cable | 83 mm |
| Bending radius, moving cable | 100 mm |
| Cable diameter | 8.3 mm |
| Cable structure | 2 x 0.51 mm² + 4 x 0.205 mm² |
| Nominal cross section conductor | 0.51 mm² |
| Conductor nominal cross section | AWG20, AWG24 |
| Degree of protection | IP20 |
| Note on degree of protection | In mounted state |
| Ambient temperature | -40 ... 80 °C |
| Ambient temperature with moving cable | -10 ... 80 °C |
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK RoHS instructions |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Note on materials | RoHS compliant |
| Pollution degree | 3 |
| Corrosion resistance class CRC | 0 - No corrosion stress |
| Material cable sheath | PVC |
| Cable sheath colour | Black |
| Material housing | PVC |
| Housing colour | Grey |
| Material insulating sheath | PVC |
| Weight | 0.28 kg |
| Manufacturer | Festo |
| Hersteller-Nr | NEBM-REG6-K-2.5-Q14N-REG6 |
| EAN | 4052568421120 |
| Zolltarifnummer | 85444290 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
