Connecting cable NEBM-L15G24-ES-5-LE24 - Festo 8178803
Net
excl. VAT
€452.29
Item
FES-8178803
Manufacturer no.
NEBM-L15G24-ES-5-LE24
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Cable designation | Without inscription label holder |
|---|---|
| Product weight | 510 g |
| Electrical connection 1, function | Field device side |
| Electrical connection 1, connection type | 4x socket |
| Electrical connection 1, cable outlet | Straight |
| Electrical connection 1, connector system | Connection pattern L15 |
| Electrical connection 1, number of connections/cores | 24 |
| Electrical connection 1, used connections/cores | 24 |
| Electrical connection 2, function | Control side |
| Electrical connection 2, connection type | 4x cable |
| Electrical connection 2, connector system | Open end |
| Electrical connection 2, number of connections/cores | 24 |
| Electrical connection 2, used connections/cores | 24 |
| Nominal operating voltage DC | 24 V |
| Shielding | Yes |
| Cable length | 5 m |
| Cable characteristic | Suitable for energy chains |
| Bending radius, fixed cable | 23.1 mm |
| Bending radius, moving cable | 33 mm |
| Cable diameter | 3.3 ... 4.6 mm |
| Cable structure | 2 x 4 x 0.25 mm² + 2 x 8 x 0.08 mm² |
| Nominal cross section conductor | 0.08 ... 0.25 mm² |
| Wire ends | Wire ferrule |
| Ambient temperature | -30 ... 70 °C |
| Ambient temperature with moving cable | -5 ... 70 °C |
| Storage temperature | -30 ... 70 °C |
| Relative air humidity | 0 - 100% |
| Nominal altitude of use | <= 2000 m NHN |
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK instructions for EMC |
| KC mark | KC-EMV |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Note on materials | RoHS compliant |
| Material cable sheath | PUR |
| Weight | 0.1 kg |
| Manufacturer | Festo |
| Hersteller-Nr | NEBM-L15G24-ES-5-LE24 |
| EAN | 4052568633387 |
| Zolltarifnummer | 85444290 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
