Control cable 0.5 m, 36-pin SCSI plug to 36-pin Screw terminal terminal strip NEBC-S2G36-K-0.5-N-C2W36-S7 - Festo 5105646
Control cable NEBC-S2G36-K-0.5-N-C2W36-S7, 0.5 m long: SCSI plug (36-pin), straight at one end, terminal strip with screw terminal (36-pin), straight at the other. For fixed installation the bending radius is 74 mm. Current rating 1.5 A at 40 °C, PVC sheath. Operating voltage 0 to 30 V DC.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With a cable length of 0.5 m and a current rating of 1.5 A, the control cable NEBC-S2G36-K-0.5-N-C2W36-S7 connects field device and controller.
Benefits
- Field device side: SCSI plug (36-pin), straight
- Control side: terminal strip with screw terminal (36-pin), straight
- Bending radius: 74 mm in fixed installation
- Electrical: 1.5 A at 40 °C, 0 to 30 V DC
- Cable sheath: PVC, diameter 7.4 mm
- Environment: IP20, -40 to 80 °C
Applications
Use between field device and controller at -40 to 80 °C.
Technical data
| Cable designation | Without inscription label holder |
|---|---|
| Electrical connection 1, function | Field device side |
| Electrical connection 1, design | Square |
| Electrical connection 1, connection type | Plug |
| Electrical connection 1, cable outlet | Straight |
| Electrical connection 1, connector system | SCSI |
| Electrical connection 1, number of connections/cores | 36 |
| Electrical connection 1, used connections/cores | 36 |
| Electrical connection 2, function | Control side |
| Electrical connection 2, design | Square |
| Electrical connection 2, connection type | Terminal strip |
| Electrical connection 2, cable outlet | Straight |
| Electrical connection 2, connector system | Screw terminal |
| Electrical connection 2, number of connections/cores | 36 |
| Electrical connection 2, used connections/cores | 36 |
| Electrical connection 2, type of mounting | for DIN rail |
| Operational voltage range DC | 0 to 30 V |
| Operational voltage range AC | 0 to 30 V |
| Current rating at 40 °C | 1.5 A |
| Immunity to surge | 0.5 kV |
| Cable length | 0.5 m |
| Cable characteristic | Standard |
| Bending radius, fixed cable | 74 mm |
| Bending radius, moving cable | 110 mm |
| Cable diameter | 7.4 mm |
| Cable structure | 18 x 2 x 0.09 mm² |
| Nominal cross section conductor | 0.09 mm² |
| Degree of protection | IP20 |
| Note on degree of protection | In mounted state |
| Ambient temperature | -40 to 80 °C |
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK RoHS instructions |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Note on materials | RoHS compliant |
| Pollution degree | 1 |
| Corrosion resistance class CRC | 0 - No corrosion stress |
| Material cable sheath | PVC |
| Cable sheath colour | Black |
| Material housing | PA, PBT |
| Housing colour | Green, Black |
| Material insulating sheath | PVC |
| Weight | 0.28 kg |
| Manufacturer | Festo |
| Hersteller-Nr | NEBC-S2G36-K-0.5-N-C2W36-S7 |
| EAN | 4052568419929 |
| Zolltarifnummer | 85444290 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Colour | Black |
| min. Biegeradius [mm] | 74 |
| Series | NEBC |
| Protection rating | IP20 |
| Temperaturbereich | -40-80 °C |
| Temperature (max.) | 80 |
