Socket gate valve, brass, G 1", PN 20, DN 24, pressure rating PN 20 bar

Name: Socket gate valve, brass, G 1", PN 20, DN 24, pressure rating PN 20 bar
Brand: Fluidics equipment
SKU: FL-009537
Price: 27.81 EUR
Availability: InStock

Fluidics equipment ✓ Original product Brand new

Listed as a socket gate valve, this version shuts off the medium reliably at the seat. Selection is based on thread G 1" and pressure rating PN 20 bar.

Net

€27.81

excl. VAT

Item FL-009537

Manufacturer no. MUAS 10

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

This item shuts off the medium reliably at the seat and is listed as a socket gate valve. The data sheet states thread G 1" as well as pressure rating PN 20 bar. The stated material is brass.

Benefits

tight closure at the seat over many operating cycles, verified by thread G 1"
temperature range +1 to +80 °C
pressure rating PN 20 bar
material brass as stated in the data

Applications

This design is used for water and compressed air lines, heating systems and mechanical engineering. For the media the data sheet gives water, neutrale, flüssige Medien, keine mineralölhaltigen Medien.

Technical data

thread G	G 1"
nominal size DN [mm]	24
dimension L [mm]	51
pressure rating PN [bar]	20
dimension H [mm]	93
dimension R [mm]	55
material	brass
temperature range	+1 to +80 °C
media	water, neutrale, flüssige Medien, keine mineralölhaltigen Medien
Weight	0.41 kg
Manufacturer	Fluidics equipment
Hersteller-Nr	MUAS 10
EAN	4050571508425
Zolltarifnummer	84818081
GPSR Herstellerdaten	A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikelzustand	New
Artikel-Authentizität	Original product
