Socket 240, reducing, black malleable iron, Rp 3/8 x Rp 1/4 to Rp 3 x Rp 2 - Riegler

Riegler ✓ Original product Brand new

The socket 240 joins two male-threaded pipe ends in a straight line, with different thread sizes at each end. Black malleable iron, service temperature -20 to 300 °C. The variants differ in thread size from Rp 3/8 x Rp 1/4 to Rp 3 x Rp 2.

Net
As low as €1.67
excl. VAT
Item RGL-K1836
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The socket 240 joins two male-threaded pipe ends in a straight line, with different thread sizes at each end. The variants differ in thread size from Rp 3/8 x Rp 1/4 to Rp 3 x Rp 2.

Advantages

  • Service temperature -20 to 300 °C
  • 25 bar operating pressure from -20 to 120 °C, 20 to 25 bar from 120 to 300 °C
  • Dimensions and design to DIN EN 10242
  • Whitworth pipe threads to ISO 7-1, compatible with standard pipes and valves
  • Material: black malleable iron B350-10, design symbol A
  • Black surface, not galvanised

Applications

Black malleable iron fittings are the classic threaded fitting series in pipework.

Technical data

ManufacturerRiegler
DesignSocket 240, reducing
Thread 1Rp 3/8, 1/2, 3/4, 1, 1 1/4, 1 1/2, 2, 2 1/2, 3 female
Thread 2Rp 1/4, 3/8, 1/2, 3/4, 1, 1 1/4, 1 1/2, 2 female
Thread standardISO 7-1
MaterialBlack malleable iron B350-10, design symbol A
Surfaceblack
Temperature range-20 to 300 °C
Operating pressure at -20 to 120 °C25 bar
Operating pressure at 120 to 300 °C20 to 25 bar
StandardDIN EN 10242
Type no. of variantsTFM 240-3814-S, TFM 240-1214-S, TFM 240-1238-S, TFM 240-3438-S, TFM 240-3412-S, TFM 240-1038-S, TFM 240-1012-S, TFM 240-1034-S, TFM 240-11412-S, TFM 240-11434-S, TFM 240-11410-S, TFM 240-11212-S, TFM 240-11234-S, TFM 240-11210-S, TFM 240-2012-S, TFM 240-2034-S, TFM 240-2010-S, TFM 240-20114-S, TFM 240-20112-S, TFM 240-21220-S, TFM 240-3020-S
GPSR HerstellerdatenRiegler & Co. KG, Schützenstraße 27, DE-72574 Bad Urach, www.riegler.de
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Thread typeInternal thread
Thread type 2Internal thread
NormDIN EN 10242
Temperature (max.)300
