Wartungsgeräte-Kombination MSB6N-1/2:J1M1D1A1-WP - Festo 541472
Wartungsgeräte-Kombination MSB6N-1/2:J1M1D1A1-WP - Festo 541472 Wartungsgeräte-Kombination MSB6N-1/2:J1M1D1A1-WP - Festo 541472

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Service unit combination MSB6N-1/2:J1M1D1A1-WP - Festo 541472

Festo ✓ Original product Brand new
Net
€522.84
excl. VAT
Item FES-541472
Manufacturer no. MSB6N-1/2:J1M1D1A1-WP
Save Compare
Question about this item
Datasheet (PDF)
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Technical data

Size6
SeriesMS
Actuator lockRotary knob with detent, can be closed with accessories
Mounting positionVertical +/-5°
Grade of filtration40 µm
Condensate drainManual, rotating
DesignFilter regulator with pressure gauge, Standard mist lubricators
Controller functionOutput pressure constant, With primary pressure compensation, With secondary exhausting, With return flow function
Bowl guardPlastic bowl guard
Pressure gauge (ANALOG) or Pressure display (DIGITAL)With pressure gauge
Operating pressure4.5 ... 18 bar
Pressure regulation range4 ... 12 bar
Standard nominal flow rate (standardised to DIN 1343)2000 l/min
Characteristic coil data24 V DC: 1.5 W
Operating mediumInert gas
Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Storage temperature-10 ... 60 °C
Suitable for use with foodSee supplementary material information
Air purity class at outputCompressed air to ISO 8573-1:2010 [7:4:-]
Media temperature-10 ... 60 °C
Ambient temperature-10 ... 60 °C
Product weight3000 g
Type of mountingWith accessories
Pneumatic connection, port 11/2 NPT
Pneumatic connection, port 21/2 NPT
Pneumatic connection, port 3G1/2
Note on materialsRoHS compliant
Material housingDie-cast aluminium
Material bowlMakrolon®
ManufacturerFesto
Hersteller-NrMSB6N-1/2:J1M1D1A1-WP
EAN4052568347147
Zolltarifnummer84811005
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
