Fine filter 1 µm 3/4 NPT size 9 MS9-LFM-N3/4-BUM - Festo 553090
With a 1 µm grade of filtration, the fine filter MS9-LFM-N3/4-BUM supplies clean compressed air to sensitive consumers. At a glance: port 3/4 NPT, flow rate 7000 l/min and operating pressure 0 to 20 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo fine filter MS9-LFM-N3/4-BUM at a glance: grade of filtration 1 µm, residual oil content 0.5 mg/m³ and 7000 l/min flow rate. The fine filter MS9-LFM-N3/4-BUM cleans compressed air with a 1 µm grade of filtration to purity class ISO 8573-1:2010 [5:4:3].
Advantages
- Grade of filtration 1 µm, air purity class at the outlet ISO 8573-1:2010 [5:4:3].
- Residual oil content at the outlet 0.5 mg/m³.
- Filter efficiency 99.99 %.
- Max. standard flow rate for clean air class 7000 l/min.
- Condensate drain manual, rotating, condensate volume up to 225 ml.
- Operating pressure 0 to 20 bar.
Application
The fine filter MS9-LFM-N3/4-BUM sits in the compressed air line upstream of valves and actuators and keeps particles and condensate away from them. Mounting position vertical ±5° and operating medium compressed air to ISO 8573-1:2010 [6:4:4].
Technical data
| Type | MS9-LFM-N3/4-BUM |
|---|---|
| Series | MS |
| Size | 9 |
| Design | Fibre filter |
| Grade of filtration | 1 µm |
| Condensate drain | Manual, rotating |
| Operating pressure | 0 to 20 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [6:4:4] |
| Air purity class at output | Compressed air to ISO 8573-1:2010 [5:4:3] |
| Max. standard flow rate for clean air class | 7000 l/min |
| Min. standard flow rate for clean air class | 350 l/min |
| Filter efficiency | 99.99 % |
| Max. condensate volume | 225 ml |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Class 7 according to ISO 14644-1 |
| Media temperature | -10 to 60 °C |
| Ambient temperature | -10 to 60 °C |
| Storage temperature | -10 to 60 °C |
| Filter efficiency, fine particles | 99 % |
| Residual oil content | 0.5 mg/m³ |
| Filter efficiency, oil aerosol | 90 % |
| Explosion ambient temperature | -10 to 60 °C |
| Type of mounting | With accessories |
| Mounting position | Vertical ±5° |
| Pneumatic connection, port 1 | 3/4 NPT |
| Pneumatic connection, port 2 | 3/4 NPT |
| Material housing | Die-cast aluminium |
| Material covering | PA |
| Material filter | Borosilicate fibre |
| Material bowl | Wrought aluminium alloy |
| Material screen | PA |
| Material seals | NBR |
| Product weight | 2000 g |
| Manufacturer | Festo |
| Hersteller-Nr | MS9-LFM-N3/4-BUM |
| EAN | 4052568358174 |
| Zolltarifnummer | 84213925 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Seal material | NBR |
| Housing material | Die-cast aluminium |
| Medium | Compressed air |
| Filter grade [µm] | 1 |
| Betriebsdruck max [bar] | 20 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
