Micro filter MS9-LFM-N3/4-AUM-HF - Festo 552980

Name: Micro filter MS9-LFM-N3/4-AUM-HF - Festo 552980
Brand: Festo
SKU: FES-552980
Price: 550.85 EUR
Availability: InStock

Festo ✓ Original product Brand new

Net

€550.85

excl. VAT

Item FES-552980

Manufacturer no. MS9-LFM-N3/4-AUM-HF

Datasheet (PDF)

Technical data

Series	MS
Size	9
Design	Fibre filter
Grade of filtration	0.01 µm
Condensate drain	Manual, rotating
Operating pressure	0 ... 20 bar
Operating medium	Compressed air to ISO 8573-1:2010 [6:4:4]
Air purity class at output	Compressed air to ISO 8573-1:2010 [3:4:2]
Max. standard flow rate for clean air class	7800 l/min
Min. standard flow rate for clean air class	390 l/min
Filter efficiency	99.9999 %
Max. condensate volume	225 ml
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Cleanroom suitability, measured according to ISO 14644-14	Class 7 according to ISO 14644-1
Media temperature	-10 ... 60 °C
Ambient temperature	-10 ... 60 °C
Storage temperature	-10 ... 60 °C
Filter efficiency, fine particles	99.995 %
MPPS	0.1 µm
Filter efficiency MPPS	99.968 %
Residual oil content	0.01 mg/m³
Filter efficiency, oil aerosol	99 %
Type of mounting	With accessories
Mounting position	Vertical +/-5°
Pneumatic connection, port 1	3/4 NPT
Pneumatic connection, port 2	3/4 NPT
Material housing	Die-cast aluminium
Material covering	PA
Material filter	Borosilicate fibre
Material bowl	Wrought aluminium alloy
Material screen	PA
Material seals	NBR
Product weight	2500 g
Manufacturer	Festo
Hersteller-Nr	MS9-LFM-N3/4-AUM-HF
EAN	4052568357894
Zolltarifnummer	84213925
GPSR Herstellerdaten	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Artikelzustand	New
Artikel-Authentizität	Original product
