Micro filter 0.01 µm 1 NPT size 9 MS9-LFM-N1-AUM-DA - Festo 553024
The micro filter MS9-LFM-N1-AUM-DA cleans compressed air with a 0.01 µm grade of filtration to purity class ISO 8573-1:2010 [3:4:2]. Characteristics: port 1 NPT, flow rate 6500 l/min and operating pressure 0 to 20 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo micro filter MS9-LFM-N1-AUM-DA at a glance: grade of filtration 0.01 µm, residual oil content 0.01 mg/m³ and 6500 l/min flow rate. The micro filter MS9-LFM-N1-AUM-DA retains particles from 0.01 µm in the compressed air and protects downstream valves and actuators.
Advantages
- Grade of filtration 0.01 µm, air purity class at the outlet ISO 8573-1:2010 [3:4:2].
- Residual oil content at the outlet 0.01 mg/m³.
- Filter efficiency 99.9999 %.
- Max. standard flow rate for clean air class 6500 l/min.
- Condensate drain manual, rotating, condensate volume up to 225 ml.
- Operating pressure 0 to 20 bar.
Application
The micro filter MS9-LFM-N1-AUM-DA sits in the compressed air line upstream of valves and actuators and keeps particles and condensate away from them. For installation: mounting position vertical ±5° and operating medium compressed air to ISO 8573-1:2010 [6:4:4].
Technical data
| Type | MS9-LFM-N1-AUM-DA |
|---|---|
| Series | MS |
| Size | 9 |
| Design | Fibre filter |
| Grade of filtration | 0.01 µm |
| Condensate drain | Manual, rotating |
| Operating pressure | 0 to 20 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [6:4:4] |
| Air purity class at output | Compressed air to ISO 8573-1:2010 [3:4:2] |
| Max. standard flow rate for clean air class | 6500 l/min |
| Min. standard flow rate for clean air class | 325 l/min |
| Filter efficiency | 99.9999 % |
| Max. condensate volume | 225 ml |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Class 7 according to ISO 14644-1 |
| Media temperature | -10 to 60 °C |
| Ambient temperature | -10 to 60 °C |
| Storage temperature | -10 to 60 °C |
| Filter efficiency, fine particles | 99.995 % |
| MPPS | 0.08 µm |
| Filter efficiency MPPS | 99.981 % |
| Residual oil content | 0.01 mg/m³ |
| Filter efficiency, oil aerosol | 99 % |
| Differential pressure display | Visual indicator |
| Type of mounting | With accessories |
| Mounting position | Vertical ±5° |
| Pneumatic connection, port 1 | 1 NPT |
| Pneumatic connection, port 2 | 1 NPT |
| Material housing | Die-cast aluminium |
| Material covering | PA |
| Material filter | Borosilicate fibre |
| Material bowl | Wrought aluminium alloy |
| Material screen | PA |
| Material seals | NBR |
| Product weight | 2000 g |
| Manufacturer | Festo |
| Hersteller-Nr | MS9-LFM-N1-AUM-DA |
| EAN | 4052568358020 |
| Zolltarifnummer | 84213925 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Seal material | NBR |
| Housing material | Die-cast aluminium |
| Medium | Compressed air |
| Filter grade [µm] | 0,01 |
| Betriebsdruck max [bar] | 20 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
