Membrane air dryer MS6N-LDM1-3/8-P20 - Festo 543654
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Size | 6 |
|---|---|
| Series | MS |
| Mounting position | Vertical +/-5° |
| Design | Membrane air dryer |
| Operating pressure | 3 ... 12.5 bar |
| Standard nominal flow rate (standardised to DIN 1343) | 200 l/min |
| Operating medium | Compressed air to ISO 8573-1:2010 [1:4:2] |
| Note on operating and pilot medium | Lubricated operation not possible |
| Pressure dew point drop | 20 K |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Storage temperature | -20 ... 60 °C |
| Suitable for use with food | See supplementary material information |
| Air purity class at output | Compressed air to ISO 8573-1:2010 [1:3:2] |
| Media temperature | 2 ... 50 °C |
| Ambient temperature | 2 ... 50 °C |
| Product weight | 1050 g |
| Type of mounting | With accessories |
| Pneumatic connection, port 1 | 3/8 NPT |
| Pneumatic connection, port 2 | 3/8 NPT |
| Note on materials | RoHS compliant |
| Material housing | Die-cast aluminium |
| Material bowl | Wrought aluminium alloy |
| Manufacturer | Festo |
| Hersteller-Nr | MS6N-LDM1-3/8-P20 |
| EAN | 4052568348762 |
| Zolltarifnummer | 84213925 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
