Fine filter 0.01 µm G1/2 size 6 MS6-LFM-1/2-ARM-Z - Festo 527670
The fine filter MS6-LFM-1/2-ARM-Z retains particles from 0.01 µm in the compressed air and protects downstream valves and actuators. At a glance: port G1/2, condensate drain manual and media temperature -10 to 60 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The key values of the fine filter MS6-LFM-1/2-ARM-Z: grade of filtration 0.01 µm and port G1/2. With a 0.01 µm grade of filtration, the fine filter MS6-LFM-1/2-ARM-Z supplies clean compressed air to sensitive consumers.
Advantages
- Grade of filtration 0.01 µm, filter material borosilicate fibre.
- Condensate drain manual.
- Pneumatic connection G1/2.
- Corrosion resistance class CRC 2, LABS (PWIS) conformity VDMA24364-B1/B2-L.
Application
A typical position for the fine filter MS6-LFM-1/2-ARM-Z is the service unit right after the on/off valve or upstream of sensitive consumers. For installation: mounting position vertical ±5° and operating medium compressed air to ISO 8573-1:2010 [6:4:4].
Technical data
| Type | MS6-LFM-1/2-ARM-Z |
|---|---|
| Series | MS |
| Size | 6 |
| Design | Fibre filter |
| Operating medium | Compressed air to ISO 8573-1:2010 [6:4:4] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Suitable for use with food | See supplementary material information |
| Media temperature | -10 to 60 °C |
| Ambient temperature | -10 to 60 °C |
| Type of mounting | With accessories |
| Mounting position | Vertical ±5° |
| Material housing | Die-cast aluminium |
| Material filter | Borosilicate fibre |
| Material seals | NBR |
| Note on materials | RoHS compliant |
| Pneumatic connection, port 1 | G1/2 |
| Pneumatic connection, port 2 | G1/2 |
| Grade of filtration | 0.01 µm |
| Material bowl | PC |
| Bowl guard | Plastic bowl guard |
| Condensate drain | Manual |
| Weight (price list) | 0.7 kg |
| Weight | 0.7 kg |
| Manufacturer | Festo |
| Hersteller-Nr | MS6-LFM |
| Zolltarifnummer | 84213925 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/2 |
| Size BG | 6 |
| Seal material | NBR |
| Housing material | Die-cast aluminium |
| Medium | Compressed air |
| Filter grade [µm] | 0,01 |
| Pneumatic connection | G1/2 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
