Branching module G1/2, 4 ports MS6-FRM-1/2-A4-F1A - Festo 8183566

Festo ✓ Original product Brand new

The MS6-FRM-1/2-A4-F1A branching module taps compressed air within an MS6 service unit combination, for example upstream of the lubricator. Main flow reaches 14700 l/min, operating pressure up to 20 bar.

Net
€48.37
excl. VAT
Item FES-8183566
Manufacturer no. MS6-FRM-1/2-A4-F1A
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo MS6-FRM-1/2-A4-F1A provides additional outlets, 4 ports G1/2 in total.

At a glance

  • 14700 l/min in main flow direction
  • Upper outlet 4400 l/min, lower 4600 l/min
  • Operating pressure 0 to 20 bar
  • Media temperature -10 to 60 °C
  • Corrosion resistance class CRC 2

Applications

The MS6-FRM-1/2-A4-F1A supplies sub-circuits with unlubricated compressed air while the main flow continues to the next station.

Technical data

TypeMS6-FRM-1/2-A4-F1A
Festo part number8183566
Mounting positionAny
DesignBranching module
Operating pressure0 to 20 bar
Standard nominal flow rate in main flow direction 1 to 214700 l/min
Standard nominal flow rate, outlet upwards4400 l/min
Standard nominal flow rate, outlet downwards4600 l/min
Operational voltage range AC0 to 250 V
Operational voltage range DC0 to 125 V
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4], inert gas
Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Suitability for the production of Li-ion batteriesSuitable for battery production with reduced Cu/Zn/Ni values (F1a)
Storage temperature-10 to 60 °C
Suitable for use with foodSee supplementary material information
Media temperature-10 to 60 °C
Ambient temperature-10 to 60 °C
Product weight458 g
Pneumatic connection, port 1G1/2
Pneumatic connection, port 2G1/2
Pneumatic connection, port 3G1/2
Pneumatic connection, port 4G1/2
Note on materialsRoHS compliant
Material housingDie-cast aluminium
Weight0.55 kg
ManufacturerFesto
Hersteller-NrMS6-FRM-1/2-A4-F1A
EAN4052568637545
Zolltarifnummer76169910
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/2
Housing materialDie-cast aluminium
MediumCompressed air, neutral gases
SeriesMS6
Betriebsdruck max [bar]20
Pneumatic connectionG1/2
Temperaturbereich-10-60 °C
Temperature (max.)60
