Filter 5 to 40 µm, 1000 to 1700 l/min, MS4 series MS4-LF - Festo 527695

Festo ✓ Original product Brand new

The MS4-LF filter removes particles and condensate from the compressed air, with a grade of filtration of 5 to 40 µm. Drain: manual, non-detenting, manual, rotating, Semi-automatic.

Net
€56.52
excl. VAT
Item FES-527695
Manufacturer no. MS4-LF
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The filter element of the MS4-LF works as a sintered filter with centrifugal separator with 5 to 40 µm grade of filtration.

Why it pays off

  • 1000 to 1700 l/min standard nominal flow rate to DIN 1343
  • Grade of filtration 5 to 40 µm, condensate separation 75 %
  • Operating pressure 0 to 14 bar
  • Media temperature -10 to 60 °C
  • Corrosion resistance class CRC 2
  • Approval c UL us - Recognised (Oil)

Applications

The MS4-LF sits at the start of the preparation chain and protects downstream regulators, valves and drives.

Technical data

TypeMS4-LF
Festo part number527695
Size4
SeriesMS
Mounting positionVertical ±5°
Grade of filtration5 to 40 µm
Condensate drainManual, non-detenting, manual, rotating, Semi-automatic
DesignSintered filter with centrifugal separator
Bowl guardPlastic bowl guard, integrated as metal bowl
Degree of condensate separation75 %
Operating pressure0 to 14 bar
Standard nominal flow rate (standardised to DIN 1343)1000 to 1700 l/min
Approvalc UL us - Recognised (Oil)
CE mark (see declaration of conformity)To EU Explosion Protection Directive (ATEX)
UKCA marking (see declaration of conformity)To UK EX instructions
Explosion protectionZone 1 (ATEX), zone 2 (ATEX), zone 21 (ATEX), zone 22 (ATEX)
ATEX category gasII 2G
ATEX category dustII 2D
Explosion ignition protection type for gasEx h IIC T6 Gb X
Explosion ignition protection type for dustEx h IIIC T60°C Db X
Explosion ambient temperature-10°C ≤ Ta ≤ +60°C
Operating mediumCompressed air to ISO 8573-1:2010 [7:9:-], inert gas
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Storage temperature-10 to 60 °C
Suitable for use with foodSee supplementary material information
Media temperature-10 to 60 °C
Ambient temperature-10 to 60 °C
Type of mountingWith accessories
Note on materialsRoHS compliant
Material sub-baseDie-cast aluminium
Material sealsNBR
Material filterPE
Material housingDie-cast aluminium
Material separating platePOM
Weight0.41 kg
ManufacturerFesto
Hersteller-NrMS4-LF
Zolltarifnummer84213925
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Size BG4
Seal materialNBR
Housing materialDie-cast aluminium
MediumCompressed air, neutral gases
Betriebsdruck max [bar]14
Temperaturbereich-10-60 °C
Temperature (max.)60
