Pressure regulator MS2 QS-6 regulating range 0.5 to 7 bar MS2-LR-QS6-D6-A8-B - Festo 8086640
Keeps the working pressure constant within 0.5 to 7 bar and shields downstream actuators from fluctuations in the supply network. Festo MS2-LR-QS6-D6-A8-B with QS-6 ports and a standard nominal flow rate of 350 l/min, size 2. Gauge port G1/8 prepared. Cleanroom class 6 to ISO 14644-1.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo MS2-LR-QS6-D6-A8-B lets you set the pressure for a machine or sub-circuit between 0.5 and 7 bar. With a standard nominal flow rate of 350 l/min and QS-6 ports, the MS2-LR-QS6-D6-A8-B is designed for small consumers, the compact housing is made of reinforced PA.
Benefits
- Standard nominal flow rate 350 l/min with QS-6 ports
- Max. pressure hysteresis 0.25 bar for repeatable settings
- Secondary exhaust vents excess output pressure when the setting is reduced
- Return flow function exhausts the output side as soon as the inlet is depressurised
- Rotary knob with detent fixes the set value
- Cleanroom suitable to ISO 14644-1 class 6, PWIS conformity VDMA24364-B1/B2-L
Application
Mounting with accessories, ambient temperature -5 to 50 °C. The MS2-LR-QS6-D6-A8-B operates with compressed air to ISO 8573-1:2010 [7:4:4] or inert gases. Corrosion resistance class CRC 1.
Technical data
| Order code | MS2-LR-QS6-D6-A8-B |
|---|---|
| Festo part number | 8086640 |
| Weight | 0.033 kg |
| Size | 2 |
| Series | MS |
| Actuator lock | rotary knob with detent |
| Mounting position | any |
| Design | directly actuated diaphragm regulator |
| Regulator function | constant output pressure, with secondary exhaust, with return flow function |
| Pressure indication | prepared for G1/8 |
| Operating pressure | 1 to 8 bar |
| Pressure regulation range | 0.5 to 7 bar |
| Max. pressure hysteresis | 0.25 bar |
| Standard nominal flow rate | 350 l/min |
| Operating medium | compressed air to ISO 8573-1:2010 [7:4:4], inert gases |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| PWIS conformity | VDMA24364-B1/B2-L |
| Cleanroom suitability, measured to ISO 14644-14 | class 6 to ISO 14644-1 |
| Storage temperature | -5 to 50 °C |
| Medium temperature | -5 to 50 °C |
| Ambient temperature | -5 to 50 °C |
| Type of mounting | with accessories |
| Pneumatic connection, port 1 | QS-6 |
| Pneumatic connection, port 2 | QS-6 |
| Note on materials | RoHS compliant |
| Material bottom cover | PA |
| Material seals | NBR |
| Material rotary knob | POM |
| Material spring | high-alloy steel |
| Material housing | reinforced PA |
| Material diaphragm | NBR |
| Material valve stem | wrought aluminium alloy, NBR |
| Customs tariff number | 84811099 |
| Manufacturer | Festo |
| Hersteller-Nr | MS2-LR-QS6-D6-A8-B |
| EAN | 4052568451486 |
| Zolltarifnummer | 84811099 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Size BG | 2 |
| Control range max. [bar] | 7 |
| Seal material | NBR |
| Medium | Compressed air, neutral gases |
| Flow rate [l/min] | 350 |
| Druckregelbereich [bar] | 0,5 bis 7 |
| Medientemperatur [°C] | -5 bis 50 |
| Betriebsdruck max [bar] | 8 |
| Pneumatic connection | QS-6 |
| Temperature (max.) | 50 |
