Filter for clean compressed air, M5, size 2, 5 µm MS2-LF-M5-C-P-M-F1A-B - Festo 8181093

Festo ✓ Original product Brand new

The MS2-LF-M5-C-P-M-F1A-B filter cleans the compressed air of particles and condensate. Datasheet values: port M5, size 2, operating pressure 1 to 10 bar and grade of filtration 5 µm. It suits compact air preparation close to the consumer.

Net
€43.14
excl. VAT
Item FES-8181093
Manufacturer no. MS2-LF-M5-C-P-M-F1A-B
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The MS2-LF-M5-C-P-M-F1A-B filter cleans the compressed air of particles and condensate. The key values: port M5 and size 2.

Benefits

  • Operating pressure 1 to 10 bar
  • Flow rate of 225 l/min (standard nominal flow rate)
  • Port thread M5
  • Grade of filtration 5 µm
  • Air purity at the outlet: compressed air to ISO 8573-1:2010 [6:4:4]
  • Suitable for ambient temperatures of -5 to 50 °C

Application

It suits compact air preparation close to the consumer. The MS2-LF-M5-C-P-M-F1A-B works with compressed air to ISO 8573-1:2010 [7:4:4], inert gases.

Technical data

TypeMS2-LF-M5-C-P-M-F1A-B
Festo part number8181093
Size2
SeriesMS
Mounting positionvertical ± 5°
Grade of filtration5 µm
Condensate drainmanual, rotating
Designsintered filter with centrifugal separator
Operating pressure1 to 10 bar
Standard nominal flow rate (to DIN 1343)225 l/min
Operating mediumcompressed air to ISO 8573-1:2010 [7:4:4], inert gases
Corrosion resistance class CRC1 - low corrosion stress
PWIS conformityVDMA24364-B1/B2-L
Suitability for the production of Li-ion batteriessuitable for battery production with reduced Cu/Zn/Ni content (F1a)
Cleanroom suitability, measured to ISO 14644-14class 6 to ISO 14644-1
Storage temperature-5 to 50 °C
Air purity class at outletcompressed air to ISO 8573-1:2010 [6:4:4]
Medium temperature-5 to 50 °C
Ambient temperature-5 to 50 °C
Product weight45.3 g
Mounting typewith accessories
Pneumatic port 1M5
Pneumatic port 2M5
Note on materialsRoHS-compliant
Seal materialNBR
Spring materialhigh-alloy steel
Housing materialPA, reinforced
Diaphragm materialNBR
Bowl materialPC
Weight0.049 kg
ManufacturerFesto
Hersteller-NrMS2-LF-M5-C-P-M-F1A-B
EAN4052568626921
Zolltarifnummer84213925
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MediumCompressed air
Filter grade [µm]5
Betriebsdruck max [bar]10
Temperature (max.)50
