Filter for clean compressed air, M5, size 2, 5 µm MS2-LF-M5-C-P-M-B - Festo 8183325
The MS2-LF-M5-C-P-M-B filter cleans the compressed air of particles and condensate. Main data: port M5, size 2, operating pressure 1 to 10 bar and grade of filtration 5 µm. It suits compact air preparation close to the consumer.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The MS2-LF-M5-C-P-M-B filter cleans the compressed air of particles and condensate. At a glance: port M5 and size 2.
Benefits
- Rated for an operating pressure of 1 to 10 bar
- Flow rate of 225 l/min (standard nominal flow rate)
- Pneumatic port M5 for direct piping
- Grade of filtration 5 µm
- Air purity at the outlet: compressed air to ISO 8573-1:2010 [6:4:4]
- Ambient temperature -5 to 50 °C
Application
It suits compact air preparation close to the consumer. Permissible operating medium for MS2-LF-M5-C-P-M-B: compressed air to ISO 8573-1:2010 [7:4:4], inert gases.
Technical data
| Type | MS2-LF-M5-C-P-M-B |
|---|---|
| Festo part number | 8183325 |
| Size | 2 |
| Series | MS |
| Mounting position | vertical ± 5° |
| Grade of filtration | 5 µm |
| Condensate drain | manual, rotating |
| Design | sintered filter with centrifugal separator |
| Operating pressure | 1 to 10 bar |
| Standard nominal flow rate (to DIN 1343) | 225 l/min |
| Operating medium | compressed air to ISO 8573-1:2010 [7:4:4], inert gases |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| PWIS conformity | VDMA24364-B1/B2-L |
| Cleanroom suitability, measured to ISO 14644-14 | class 6 to ISO 14644-1 |
| Storage temperature | -5 to 50 °C |
| Air purity class at outlet | compressed air to ISO 8573-1:2010 [6:4:4] |
| Medium temperature | -5 to 50 °C |
| Ambient temperature | -5 to 50 °C |
| Product weight | 45.3 g |
| Mounting type | with accessories |
| Pneumatic port 1 | M5 |
| Pneumatic port 2 | M5 |
| Note on materials | RoHS-compliant |
| Seal material | NBR |
| Spring material | high-alloy steel |
| Housing material | PA, reinforced |
| Diaphragm material | NBR |
| Bowl material | PC |
| Weight | 0.049 kg |
| Manufacturer | Festo |
| Hersteller-Nr | MS2-LF-M5-C-P-M-B |
| EAN | 4052568626945 |
| Zolltarifnummer | 84213925 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Medium | Compressed air |
| Filter grade [µm] | 5 |
| Betriebsdruck max [bar] | 10 |
| Temperature (max.) | 50 |
