Proportional pressure regulator 0 to 10 bar G1/2 MPPES-3-1/2-10-420 - Festo 187327
Electrically adjustable pressure from 0 to 10 bar: proportional pressure regulator MPPES-3-1/2-10-420 with 4-20 mA setpoint. Port G1/2, max. pressure hysteresis 0.05 bar and degree of protection IP65. Genuine Festo part 187327.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With the MPPES-3-1/2-10-420 the pressure is specified by a 4-20 mA analogue signal, the regulation range extends from 0 to 10 bar. Pneumatically it is connected via G1/2. Design: piloted piston regulator.
Key benefits
- Fine pressure control: max. pressure hysteresis 0.05 bar
- Defined safety position: if the power supply cable is interrupted, the output pressure drops to 0 bar
- For harsh environments: degree of protection IP65, corrosion resistance class CRC 2
- PWIS conformity VDMA24364-B2-L for paint shops and sensitive processes
Application and mounting
The operating medium is compressed air to ISO 8573-1:2010 [7:4:4] and inert gas. Lubricated operation is possible but must then be continued. Mounting position of the MPPES-3-1/2-10-420: any, mounting: with through-hole. Permissible ambient temperature 0 to 50 °C. Electrical connection of the MPPES-3-1/2-10-420: 8-pin, M16x0.75, plug, to DIN 45326, round design.
Technical data
| Type | MPPES-3-1/2-10-420 |
|---|---|
| Festo part number | 187327 |
| Nominal size, supply | 11 mm |
| Nominal size, exhaust | 12 mm |
| Type of actuation | Electrical |
| Sealing principle | Soft |
| Mounting position | Any |
| Design | Piloted piston regulator |
| Short circuit current rating | For all electrical connections |
| Safety instructions | Safety position MPPES: if the power supply cable is interrupted, the output pressure drops to 0 bar. |
| Reverse polarity protection | For all electrical connections |
| Valve function | 3-way proportional-pressure regulator, closed |
| Operating pressure | 12 bar |
| Pressure regulation range | 0 to 10 bar |
| Inlet pressure 1 | 11 to 12 bar |
| Max. pressure hysteresis | 0.05 bar |
| Switching time off | 450 ms |
| Switching time on | 230 ms |
| Operational voltage range DC | 18 to 30 V |
| Nominal operating voltage DC | 24 V |
| Residual ripple | 10% |
| SETPOINT/ACTUAL values | Current type 4-20 mA |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4], Inert gas |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Approval | RCM |
| KC mark | KC-EMV |
| CE mark (see declaration of conformity) | To EU EMC Directive, In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK RoHS instructions |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Media temperature | 0 to 60 °C |
| Degree of protection | IP65 |
| Ambient temperature | 0 to 50 °C |
| Product weight | 2670 g |
| Electrical connection | 8-pin, M16x0.75, Plug, To DIN 45326, Round design |
| Type of mounting | With through-hole |
| Pneumatic connection, port 1 | G1/2 |
| Pneumatic connection, port 2 | G1/2 |
| Pneumatic connection, port 3 | G1/2 |
| Note on materials | RoHS compliant |
| Material housing | Wrought aluminium alloy |
| Material membrane | NBR |
| Weight | 2.7 kg |
| Manufacturer | Festo |
| Hersteller-Nr | MPPES-3-1/2-10-420 |
| EAN | 4052568147969 |
| Zolltarifnummer | 84811099 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Aluminium |
| Thread | G 1/2 |
| Control range max. [bar] | 10 |
| Seal material | NBR |
| Medium | Compressed air, neutral gases |
| Function | 3-way proportional pressure regulating valve closed |
| Inlet pressure max. [bar] | 12 |
| Actuation type | Electrical |
| Druckregelbereich [bar] | 0 bis 10 |
| Medientemperatur [°C] | 0 bis 60 |
| Norm | DIN 45326 |
| Operating voltage | 24 V DC |
| Betriebsdruck max [bar] | 12 |
| Pneumatic connection | G1/2 |
| Protection rating | IP65 |
| Temperaturbereich | 0-50 °C |
| Temperature (max.) | 50 |
