Solenoid valve MN1H-2-1-MS-NPT - Festo 161733
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Design | Diaphragm valve |
|---|---|
| Sealing principle | Soft |
| Mounting position | Any |
| Type of mounting | Inline installation |
| Connection Process valve | 1 NPT |
| Nominal size | 25 mm |
| Valve function | 2/2-way, single solenoid, closed |
| Manual override | Detenting via accessory, Non-detenting |
| Flow direction | Non-reversible |
| Medium | Filtered compressed air, grade of filtration 200 µm |
| Exhaust-air function | Cannot be throttled |
| Type of reset | Pneumatic spring |
| Type of piloting | Piloted |
| Medium pressure | 0.5 ... 10 bar |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Media temperature | -10 ... 60 °C |
| Ambient temperature | -10 ... 60 °C |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Material screws | High-alloy stainless steel |
| Material number screw | 1,4301 |
| Product weight | 1100 g |
| Degree of protection | IP65 |
| Weight | 1.3 kg |
| Manufacturer | Festo |
| Hersteller-Nr | MN1H-2-1-MS-NPT |
| EAN | 4052568312152 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
