Miniature relief valve 07 Series, 1/8 PTF, 0.3 to 7 bar, knob, zinc alloy body - Norgren V07-100-NNKA
The Norgren V07-100-NNKA miniature relief valve limits the pressure at port 1/8 PTF to an adjustable value of 0.3 to 7 bar. Measuring 75 x 38 x 42 mm and weighing 0.19 kg, the V07-100-NNKA also fits tight spaces.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The V07-100-NNKA relief valve from the Norgren V07 series protects downstream components by opening above the set pressure. The Norgren V07-100-NNKA miniature relief valve limits the pressure at port 1/8 PTF to an adjustable value of 0.3 to 7 bar.
Benefits
- Adjustment range 0.3 to 7 bar via acetal knob
- Inlet pressure up to 20 bar, flow 6.5 dm³/s
- Temperature range -34 to 65 °C
- Compact 75 x 38 x 42 mm design, weight 0.19 kg
- Gauge port 1/8 PTF
Applications
The V07-100-NNKA is used in pilot air circuits, on small vessels and downstream of pressure regulators in assembly and handling systems.
Technical data
| Manufacturer | Norgren |
|---|---|
| Order number | V07-100-NNKA |
| Product type | Miniature relief valve |
| Series | V07 |
| Product line | 07 Series |
| Adjustment | Knob |
| Adjusting knob | Acetal |
| Port size | 1/8 PTF |
| Gauge port | 1/8 PTF |
| Maximum inlet pressure | 20 bar |
| Adjustable outlet pressure | 0.3 to 7 bar |
| Flow | 6.5 dm³/s |
| Medium | Compressed air |
| Temperature range | -34 to 65 °C |
| Body material | Zinc alloy |
| Spring bonnet | Acetal |
| Seal material | Nitrile rubber (NBR) |
| Height | 75 mm |
| Width | 38 mm |
| Length | 42 mm |
| Weight | 0.19 kg |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Customs tariff number | 84814090 |
| ECLASS | 51050103 |
| Hersteller-Nr | V07-100-NNKA |
| Zolltarifnummer | 84814090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Anschlussgröße | 1/8 PTF |
| Control range max. [bar] | 7 |
| Inlet pressure max. [bar] | 20 |
