Mini elbow flow control valve with check function, supply air control, M 5, tube 3 mm, 0 to +60 °C

The speed of a pneumatic cylinder is set through the air volume, not through the pressure. This mini elbow flow control valve with check function connects the thread M 5 to a tube of 3 mm outside diameter and works with supply air control. The throttle screw acts in one flow direction only, in the opposite direction the check valve opens fully. The materials are body Nickel-plated brass / PBT, seal NBR, retaining claw stainless steel, cartridge ZnDC nickel-plated, release ring PBT. The temperature range runs from 0 to +60 °C.

Advantages

• Temperature range of 0 to +60 °C, suitable for production environments with changing load.
• Media Compressed air, neutral gases, the valve needs no separate treatment.
• Dimensions H 26.5, L 14.0, so the design stays slim at the cylinder.
• Version supply air control, so the speed is limited on the correct side of the piston.
• Push-in connector for tube with 3 mm outside diameter, release works without tools through the release ring.

Technical data

Applications

• Production environments within the temperature range 0 to +60 °C.
• Speed adjustment on pneumatic cylinders with 3 mm tube.
• Screwing directly into cylinder end caps with thread M 5.
• Avoiding the stick-slip effect on slow running actuators.
