Solenoid valve 2/2-way single solenoid, closed QS-4 MHJ9-QS-4-MF/LP - Festo 8084273
The MHJ9-QS-4-MF/LP switches compressed air as a 2/2-way valve (single solenoid, closed) and reaches 100 l/min standard nominal flow rate. Ratings: 0.5 to 4 bar operating pressure, QS-4 port and 9 mm width.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The solenoid valve MHJ9-QS-4-MF/LP works as a 2/2-way valve (single solenoid, closed) and reaches 100 l/min standard nominal flow rate at 0.5 to 4 bar operating pressure. Further ratings: QS-4 port, 9 mm width and 24 V DC operating voltage.
Key benefits
- Flow: 100 l/min standard nominal flow rate at only 9 mm width
- Pressure range: 0.5 to 4 bar
- Switching frequency: up to 1000 Hz
- Rugged: IP40 protection, corrosion resistance class 2
- Temperature: -5 to 60 °C ambient
- Continuous duty: 100 % duty cycle
Applications
A switching frequency of up to 1000 Hz suits fast cycling tasks such as blow-off or sorting. Mounting: either in-line installation or with through-hole, grid dimension 9.5 mm. Operating medium for the MHJ9-QS-4-MF/LP: compressed air to ISO 8573-1:2010 [7:4:4], lubricated operation possible.
Technical data
| Type | MHJ9-QS-4-MF/LP |
|---|---|
| Festo part number | 8084273 |
| Valve function | 2/2-way, single solenoid, closed |
| Type of actuation | electrical |
| Width | 9 mm |
| Standard nominal flow rate | 100 l/min |
| pneumatic working port | QS-4 |
| Operating voltage | 24 V DC |
| Operating pressure | 0.5 to 4 bar |
| Design | poppet valve without spring return |
| Reset method | pneumatic spring |
| Degree of protection | IP40 |
| Grid dimension | 9.5 mm |
| Operating note | do not operate without flow., for block mounting with flow, max. ambient temperature 45°C. |
| Sealing principle | hard |
| Mounting position | any |
| Manual override | none |
| Type of piloting | direct |
| Flow direction | non-reversible |
| b value | 0.38 |
| C value | 0.4 l/sbar |
| Max. switching frequency | 1000 Hz |
| Switching time on at 0.4 MPa (4 bar, 58 psi) and 24 V when new | 0.8 ms |
| Switching time off at 0.4 MPa (4 bar, 58 psi) and 24 V when new | 0.5 ms |
| Switching time on at 0.4 MPa (4 bar, 58 psi) and 48 V when new | 0.6 ms |
| Switching time off at 0.4 MPa (4 bar, 58 psi) and 48 V when new | 0.4 ms |
| Switching time on at 0.4 MPa (4 bar, 58 psi) and 12 V when new | 1.1 ms |
| Switching time off at 0.4 MPa (4 bar, 58 psi) and 12 V when new | 0.4 ms |
| Switching time on at 0.05 MPa (0.5 bar, 7.25 psi) and 24 V when new | 0.7 ms |
| Switching time off at 0.05 MPa (0.5 bar, 7.25 psi) and 24 V when new | 0.5 ms |
| Tolerance switching time off | +15 %/-25 % |
| Tolerance switching time on | ± 15 % |
| Operational voltage range DC | 12 to 53 V |
| Duty cycle | 100% |
| Note regarding operating voltage | operation only with connecting cable MHJ9-KMH-... |
| Coil resistance R20 | 2.5 Ohm |
| Operating medium | compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | lubricated operation possible |
| Restrictions for environmental and media temperature | as a function of switching frequency (see graph) |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Storage temperature | -20 to 50 °C |
| Permissible solenoid surface temperature | 120 °C |
| Media temperature | -5 to 60 °C |
| Ambient temperature | -5 to 60 °C |
| Product weight | 30 g |
| Electrical connection | 2-pin, plug KMH |
| Type of mounting | either in-line installation or with through-hole |
| Pneumatic connection, port 1 | QS-4 |
| Pneumatic connection, port 2 | QS-4 |
| Note on materials | RoHS compliant |
| Material seals | HNBR |
| Material housing | reinforced PA |
| Material screws | steel |
| Manufacturer | Festo |
| Hersteller-Nr | MHJ9-QS-4-MF/LP |
| EAN | 4052568449803 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Seal material | HNBR |
| Medium | Compressed air |
| Function | 2/2 closed monostable |
| Flow rate [l/min] | 100 |
| Actuation type | Electrical |
| Series | MHJ9 |
| Betriebsdruck max [bar] | 4 |
| Pneumatic connection | QS-4 |
| Protection rating | IP40 |
| Temperaturbereich | -5-60 °C |
