Solenoid valve 3/2-way single solenoid, open QS-6 MHE3-MS1H-3/2O-QS-6 - Festo 525171

Festo ✓ Original product Brand new

As a 3/2-way valve (single solenoid, open), the Festo solenoid valve MHE3-MS1H-3/2O-QS-6 delivers 200 l/min standard nominal flow rate. Ratings: -0.9 to 8 bar operating pressure, QS-6 port and 14 mm width. Switching times 2.3 ms on and 2.8 ms off.

Net
€106.65
excl. VAT
Item FES-525171
Manufacturer no. MHE3-MS1H-3/2O-QS-6
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The solenoid valve MHE3-MS1H-3/2O-QS-6 works as a 3/2-way valve (single solenoid, open) and reaches 200 l/min standard nominal flow rate at -0.9 to 8 bar operating pressure. Designed with QS-6 port, 14 mm width and 24 V DC operating voltage.

Benefits at a glance

  • Flow: 200 l/min standard nominal flow rate at only 14 mm width
  • Pressure range: -0.9 to 8 bar, vacuum included
  • Switching times: 2.3 ms on, 2.8 ms off
  • Switching frequency: up to 280 Hz
  • Rugged: IP65 protection, corrosion resistance class 2
  • Temperature: -5 to 60 °C ambient

Applications

A switching frequency of up to 280 Hz suits fast cycling tasks such as blow-off or sorting. Mounting: with through-hole, grid dimension 19 mm. Operating medium for the MHE3-MS1H-3/2O-QS-6: compressed air to ISO 8573-1:2010 [7:4:4], lubricated operation possible (in which case lubricated operation will always be required).

Technical data

TypeMHE3-MS1H-3/2O-QS-6
Festo part number525171
Valve function3/2-way, single solenoid, open
Type of actuationelectrical
Width14 mm
Standard nominal flow rate200 l/min
pneumatic working portQS-6
Operating voltage24 V DC
Operating pressure-0.9 to 8 bar
Designpressure relief poppet valve
Reset methodmechanical spring
Degree of protectionIP65
ApprovalRCM, c UL us - Recognised (Oil)
CE mark (see declaration of conformity)to EU EMC Directive, in accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)to UK RoHS regulations
Nominal size3 mm
Grid dimension19 mm
Note on grid dimensionminimum distance between the valves is 5 mm
Exhaust-air functioncan be throttled
Sealing principlesoft
Mounting positionany
Manual overridenon-detenting
Type of pilotingdirect
Flow directionreversible with restrictions
Overlapnegative overlap
Reverse polarity protectionbipolar
Additional functionsprotective circuit
Operating pressure, reversible-0.9 to 1 bar
Max. switching frequency280 Hz
Switching time off2.8 ms
Switching time on2.3 ms
Tolerance switching time off+10 %/-50 %
Tolerance switching time on+10%/-30%
Switching time dispersion from 1 Hz0.2 ms
Duty cycle100%
Coil characteristics24 V DC: low-current phase 1.6 W, high-current phase 6.5 W
Permissible voltage fluctuations± 10 %
Operating mediumcompressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot mediumlubricated operation possible (in which case lubricated operation will always be required)
Vibration resistancetransport application test with severity level 2 to FN 942017-4 and EN 60068-2-6
Restrictions for environmental and media temperatureas a function of switching frequency (see graph)
Shock resistanceshock test with severity level 2 to FN 942017-5 and EN 60068-2-27
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Cleanroom suitability, measured according to ISO 14644-14class 6 according to ISO 14644-1
Media temperature-5 to 60 °C
Ambient temperature-5 to 60 °C
Product weight120 g
Electrical connection2-pin, plug
Type of mountingwith through-hole
Pneumatic connection, port 11QS-6
Pneumatic connection, port 2QS-6
Pneumatic connection, port 33QS-6
Note on materialsRoHS compliant
Material sealsHNBR, NBR
Material housingdie-cast zinc, coated
Material screwsgalvanised steel
Weight (shipping)0.15 kg
Weight0.15 kg
ManufacturerFesto
Hersteller-NrMHE3-MS1H-3/2O-QS-6
EAN4052568161439
Zolltarifnummer84812090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Nominal size DN [mm]3
Seal materialHNBR, NBR
MediumCompressed air
Function3/2 open monostable
Flow rate [l/min]200
Actuation typeElectrical
SeriesMHE3
Betriebsdruck max [bar]8
Pneumatic connectionQS-6
Protection ratingIP65
Temperaturbereich-5-60 °C
