Solenoid valve 5/2-way single solenoid QS-4 MHE2-MS1H-5/2-QS-4-K - Festo 525119

Festo ✓ Original product Brand new

As a 5/2-way valve (single solenoid), the Festo solenoid valve MHE2-MS1H-5/2-QS-4-K delivers 90 l/min standard nominal flow rate. Also -0.9 to 8 bar operating pressure, QS-4 port and 10 mm width. Switching times 1.9 ms on and 1.7 ms off.

Net
€125.86
excl. VAT
Item FES-525119
Manufacturer no. MHE2-MS1H-5/2-QS-4-K
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With 90 l/min standard nominal flow rate, the solenoid valve MHE2-MS1H-5/2-QS-4-K switches as a 5/2-way valve (single solenoid) at -0.9 to 8 bar operating pressure. Designed with QS-4 port, 10 mm width and 24 V DC operating voltage.

Key benefits

  • Flow: 90 l/min standard nominal flow rate at only 10 mm width
  • Pressure range: -0.9 to 8 bar, vacuum included
  • Switching times: 1.9 ms on, 1.7 ms off
  • Switching frequency: up to 300 Hz
  • Rugged: IP55 protection, corrosion resistance class 2
  • Temperature: -5 to 60 °C ambient

Applications

A switching frequency of up to 300 Hz suits fast cycling tasks such as blow-off or sorting. Mounting: with through-hole, grid dimension 14 mm. The MHE2-MS1H-5/2-QS-4-K operates on compressed air to ISO 8573-1:2010 [7:4:4], lubricated operation possible (in which case lubricated operation will always be required).

Technical data

TypeMHE2-MS1H-5/2-QS-4-K
Festo part number525119
Valve function5/2-way, single solenoid
Type of actuationelectrical
Width10 mm
Standard nominal flow rate90 l/min
pneumatic working portQS-4
Operating voltage24 V DC
Operating pressure-0.9 to 8 bar
Designpressure relief poppet valve
Reset methodmechanical spring
Degree of protectionIP55
ApprovalRCM, c UL us - Recognised (Oil)
CE mark (see declaration of conformity)to EU EMC Directive, in accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)to UK RoHS regulations
Nominal size2 mm
Grid dimension14 mm
Note on grid dimensionminimum distance between the valves is 4 mm
Exhaust-air functioncan be throttled
Sealing principlesoft
Mounting positionany
Manual overridenon-detenting
Type of pilotingdirect
Flow directionnon-reversible
Overlapnegative overlap
Reverse polarity protectionbipolar
Additional functionsprotective circuit
Max. switching frequency300 Hz
Switching time off1.7 ms
Switching time on1.9 ms
Tolerance switching time off+10 %/-30 %
Tolerance switching time on+10%/-30%
Switching time dispersion from 1 Hz0.2 ms
Duty cycle100%
Coil characteristics24 V DC: low-current phase 1.625 W, high-current phase 6.5 W
Permissible voltage fluctuations± 10 %
Operating mediumcompressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot mediumlubricated operation possible (in which case lubricated operation will always be required)
Vibration resistancetransport application test with severity level 2 to FN 942017-4 and EN 60068-2-6
Restrictions for environmental and media temperatureas a function of switching frequency (see graph)
Shock resistanceshock test with severity level 2 to FN 942017-5 and EN 60068-2-27
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Cleanroom suitability, measured according to ISO 14644-14class 6 according to ISO 14644-1
Media temperature-5 to 60 °C
Ambient temperature-5 to 60 °C
Product weight70 g
Electrical connectioncable
Cable length2.5 m
Type of mountingwith through-hole
Pneumatic connection, port 1QS-4
Pneumatic connection, port 2QS-4
Pneumatic connection, port 3QS-4
Pneumatic connection, port 4QS-4
Pneumatic connection, port 5QS-4
Note on materialsRoHS compliant
Material sealsHNBR, NBR
Material housingdie-cast zinc, coated
Material cable sheathPUR
Material screwsgalvanised steel
Weight (shipping)0.14 kg
Weight0.14 kg
ManufacturerFesto
Hersteller-NrMHE2-MS1H-5/2-QS-4-K
EAN4052568161194
Zolltarifnummer84812090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Nominal size DN [mm]2
Seal materialHNBR, NBR
MediumCompressed air
Function5/2 monostable
Flow rate [l/min]90
Actuation typeElectrical
SeriesMHE2
Betriebsdruck max [bar]8
Pneumatic connectionQS-4
Protection ratingIP55
Temperaturbereich-5-60 °C
