Solenoid valve 3/2-way, single solenoid, closed, 10 mm width MHA2-MS1H-3/2G-2 - Festo 196119
Switches compressed air as a 3/2-way valve (single solenoid, closed) with 100 l/min standard nominal flow rate at only 10 mm width. Operating pressure -0.9 to 8 bar, mounting on sub-base and IP65 protection. Switching times 1.7 ms on and 2 ms off, up to 330 Hz switching frequency.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
100 l/min standard nominal flow rate at 10 mm width: the Festo MHA2-MS1H-3/2G-2 works as a 3/2-way valve (single solenoid, closed). It also offers 24 V DC operating voltage, IP65 protection and mounting on sub-base. Switching times 1.7 ms on and 2 ms off, up to 330 Hz switching frequency.
Benefits
- Flow: 100 l/min standard nominal flow rate, nominal size 2 mm
- Width: 10 mm, 14 mm grid
- Pressure range: -0.9 to 8 bar
- Switching times: 1.7 ms on, 2 ms off
- Switching frequency: up to 330 Hz
- Protection: IP65, 2-pin, plug
Applications
The MHA2-MS1H-3/2G-2 is mounted on sub-base, 14 mm grid, minimum distance between the valves is 4 mm. Operating medium: compressed air to ISO 8573-1:2010 [7:4:4], lubricated operation possible (in which case lubricated operation will always be required). Reversible operation in the range -0.9 to 1 bar.
Technical data
| Type | MHA2-MS1H-3/2G-2 |
|---|---|
| Festo part number | 196119 |
| Valve function | 3/2-way, single solenoid, closed |
| Type of actuation | Electrical |
| Width | 10 mm |
| Standard nominal flow rate | 100 l/min |
| Pneumatic working port | Sub-base |
| Operating voltage | 24 V DC |
| Operating pressure | -0.9 to 8 bar |
| Design | Pressure relief poppet valve |
| Type of reset | Mechanical spring |
| Degree of protection | IP65 |
| Approval | RCM mark, c UL us - Recognized (OL) |
| CE mark (see declaration of conformity) | To EU EMC Directive, In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK RoHS instructions |
| Nominal size | 2 mm |
| Grid dimension | 14 mm |
| Note on grid dimension | Minimum distance between the valves is 4 mm |
| Exhaust-air function | Can be throttled |
| Sealing principle | Soft |
| Mounting position | Any |
| Manual override | Non-detenting |
| Type of piloting | Direct |
| Flow direction | Reversible with restrictions |
| Symbol | 00991308 |
| Overlap | Underlap |
| Reverse polarity protection | Bipolar |
| Additional functions | Protective circuit |
| Operating pressure, reversible | -0.9 to 1 bar |
| Maximum switching frequency | 330 Hz |
| Switching time off | 2 ms |
| Switching time on | 1.7 ms |
| Tolerance switching time off | +10%/-30% |
| Tolerance switching time on | +10%/-30% |
| Switching time dispersion from 1 Hz | 0.2 ms |
| Duty cycle | 100% |
| Coil characteristics | 24 V DC: low-current phase 1.25 W, high-current phase 5 W |
| Permissible voltage fluctuations | +/-10% |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Vibration resistance | Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Restrictions for environmental and media temperature | As a function of switching frequency (see graph) |
| Shock resistance | Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Class 6 according to ISO 14644-1 |
| Media temperature | -5 to 40 °C |
| Ambient temperature | -5 to 40 °C |
| Product weight | 60 g |
| Electrical connection | 2-pin, Plug |
| Type of mounting | On sub-base |
| Pneumatic connection, port 1 | Sub-base |
| Pneumatic connection, port 2 | Sub-base |
| Pneumatic connection, port 3 | Sub-base |
| Note on materials | RoHS compliant |
| Material seals | HNBR, NBR |
| Material housing | Die-cast zinc, coated |
| Material screws | Galvanised steel |
| Weight (shipping) | 0.07 kg |
| Weight | 0.07 kg |
| Manufacturer | Festo |
| Hersteller-Nr | MHA2-MS1H-3/2G-2 |
| EAN | 4052568159160 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Nominal size DN [mm] | 2 |
| Seal material | HNBR, NBR |
| Medium | Compressed air |
| Function | 3/2 closed monostable |
| Flow rate [l/min] | 100 |
| Actuation type | Electrical |
| Series | MHA2 |
| Betriebsdruck max [bar] | 8 |
| Protection rating | IP65 |
