Solenoid valve 5/3-way closed centre ISO 5599-1 size 2 MDH-5/3G-D-2-C - Festo 43471

Festo ✓ Original product Brand new

The solenoid valve MDH-5/3G-D-2-C blocks all ports in the mid-position and so holds a cylinder in place. It delivers 2300 l/min standard nominal flow rate at nominal size 11.5 mm and mounts on ISO 5599-1 sub-bases, size 2. Design: piston spool, piloted control.

Net
€302.26
excl. VAT
Item FES-43471
Manufacturer no. MDH-5/3G-D-2-C
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With 2300 l/min standard nominal flow rate at nominal size 11.5 mm, the MDH-5/3G-D-2-C is a solenoid-actuated 5/3-way valve with closed centre position for ISO 5599-1 sub-bases, size 2.

Benefits

  • Port pattern for ISO 5599-1 sub-bases, size 2 (width 54 mm, grid dimension 56 mm)
  • Standard nominal flow rate 2300 l/min at nominal size 11.5 mm
  • Piloted control, piston spool design

Applications

As for switching behaviour, it blocks all ports in the mid-position and so holds a cylinder in place. The MDH-5/3G-D-2-C suits cylinders that must stop in an intermediate position when the signals drop. The values in the table are derived from the order code.

Technical data

FeatureValue
TypeMDH-5/3G-D-2-C
Valve function5/3-way, closed
Type of actuationElectrical
Construction width54 mm
Standard nominal flow rate2300 l/min
DesignPiston spool
Nominal size11.5 mm
Grid dimension56 mm
Conforms to standardISO 5599-1
Type of pilotingPiloted
Pneumatic connection, port 1Sub-base size 2 to ISO 5599-1
Pneumatic connection, port 2Sub-base size 2 to ISO 5599-1
Pneumatic connection, port 3Sub-base size 2 to ISO 5599-1
Pneumatic connection, port 4Sub-base size 2 to ISO 5599-1
Pneumatic connection, port 5Sub-base size 2 to ISO 5599-1
Weight0.32 kg
ManufacturerFesto
Hersteller-NrMDH-5/3G-D-2-C
Zolltarifnummer84812090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Nominal size DN [mm]11,5
Function5/3 closed
Flow rate [l/min]2300
Actuation typeElectrical
NormISO 5599-1
SeriesMDH
