Solenoid valve 5/2-way monostable ISO 5599-1 size 4 MDH-5/2-D-4-FR - Festo 35636
Festo type MDH-5/2-D-4-FR controls double-acting actuators and returns to its normal position when the signal drops. It delivers 6000 l/min standard nominal flow rate at nominal size 18 mm and mounts on ISO 5599-1 sub-bases, size 4. Design: piston spool, piloted control.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With 6000 l/min standard nominal flow rate at nominal size 18 mm, the MDH-5/2-D-4-FR is a solenoid-actuated monostable 5/2-way valve for ISO 5599-1 sub-bases, size 4.
Benefits
- Port pattern for ISO 5599-1 sub-bases, size 4 (width 76 mm, grid dimension 82 mm)
- Standard nominal flow rate 6000 l/min at nominal size 18 mm
- Piloted control, piston spool design
Applications
As for switching behaviour, it controls double-acting actuators and returns to its normal position when the signal drops. With the MDH-5/2-D-4-FR, double-acting cylinders, rotary actuators and grippers can be controlled. The values in the table are derived from the order code.
Technical data
| Feature | Value |
|---|---|
| Type | MDH-5/2-D-4-FR |
| Valve function | 5/2-way, monostable |
| Type of actuation | Electrical |
| Construction width | 76 mm |
| Standard nominal flow rate | 6000 l/min |
| Design | Piston spool |
| Nominal size | 18 mm |
| Grid dimension | 82 mm |
| Conforms to standard | ISO 5599-1 |
| Type of piloting | Piloted |
| Pneumatic connection, port 1 | Sub-base size 4 to ISO 5599-1 |
| Pneumatic connection, port 2 | Sub-base size 4 to ISO 5599-1 |
| Pneumatic connection, port 3 | Sub-base size 4 to ISO 5599-1 |
| Pneumatic connection, port 4 | Sub-base size 4 to ISO 5599-1 |
| Pneumatic connection, port 5 | Sub-base size 4 to ISO 5599-1 |
| Weight | 2 kg |
| Manufacturer | Festo |
| Hersteller-Nr | MDH-5/2-D-4-FR |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Nominal size DN [mm] | 18 |
| Function | 5/2 monostable |
| Flow rate [l/min] | 6000 |
| Actuation type | Electrical |
| Norm | ISO 5599-1 |
| Series | MDH |
