MD/49 series direct acting solenoid valve manifold, G1/8, 3/2, NC - Norgren DM/49/MAZ12J/T2
The compact body also fits tight cabinets and valve islands. The MD/49 series direct acting solenoid valve manifold Norgren DM/49/MAZ12J/T2 reaches a flow of 30 l/min and runs on an operating voltage of 12 V DC.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Directional valves control the air path to cylinders, grippers and actuators. The MD/49 series direct acting solenoid valve manifold Norgren DM/49/MAZ12J/T2 draws 2 W and covers the temperature range -20 to 50 °C.
Benefits
- Compact installation
- Manual override as standard
- Removable encapsulated coils
- Port size G1/8
- Operating pressure 0 to 10 bar
- Flow 30 l/min
Applications
The valve is used in assembly, packaging and handling systems and in valve islands.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65 with sealed plug.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren DM/49/MAZ12J/T2 |
| Series | DM/49 |
| Product line | Excel 22 |
| Valve function | 3/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Poppet |
| Mounting | Manifold |
| Port size | G1/8 |
| Operating pressure | 0 to 10 bar |
| Flow | 30 l/min |
| Medium | Compressed air |
| Temperature range | -20 to 50 °C |
| Body material | Polyamide (PA) |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | 22 mm industrial standard |
| Operating voltage | 12 V DC |
| Power consumption | 2 W |
| Coil code | QM/48/12J/21 |
| Protection class | IP65 with sealed plug |
| Height | 74.5 mm |
| Width | 62 mm |
| Length | 45 mm |
| Weight | 0.3 kg |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | DM/49/MAZ12J/T2 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
