Maxseal ICO4S 24Vdc direct acting 3/2 stainless steel 1/4 NPT ported valve - Norgren Y123AA1H1BS
Can be exchanged quickly during service. The Maxseal ICO4S 24Vdc direct acting 3/2 stainless steel 1/4 NPT ported valve Norgren Y123AA1H1BS works at an operating pressure of 12 bar and covers the temperature range -50 to 90 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Directional valves control the air path to cylinders, grippers and actuators. The Maxseal ICO4S 24Vdc direct acting 3/2 stainless steel 1/4 NPT ported valve Norgren Y123AA1H1BS runs on an operating voltage of 24 V DC and has a body made of stainless steel.
Benefits
- Port size 1/4 NPT
- Operating pressure 12 bar
- Temperature range -50 to 90 °C
- Body made of Stainless steel
- Operating voltage 24 V DC
- Protection class IP66 X8, NEMA 4X
Applications
The valve is used in assembly, packaging and handling systems and in valve islands.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP66 X8, NEMA 4X.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren Y123AA1H1BS |
| Series | ICO4S |
| Port size | 1/4 NPT |
| Operating pressure | 12 bar |
| Temperature range | -50 to 90 °C |
| Body material | Stainless steel |
| Electrical connection | M20 x 1.5 |
| Operating voltage | 24 V DC |
| Protection class | IP66 X8, NEMA 4X |
| Height | 82 mm |
| Width | 210 mm |
| Length | 82 mm |
| Weight | 6.6 kg |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | Y123AA1H1BS |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
