Gauge shut-off valve, G 1/2", 400 bar, 1.4571, temperature range -20 to +200 °C, DIN 16270 A

Wika ✓ Original product Brand new

Isolates plant sections for maintenance and conversion. The nominal pressure PN covers 400 bar. The connection is made via thread G 1/2".

Net
€220.21
excl. VAT
Item FL-034046
Manufacturer no. MAV 12 SMSM ES
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Within the line this gauge shut-off valve handles switching of the medium at exactly one point. The body is made of 1.4571. The device is screwed in with G 1/2". The nominal pressure PN extends over 400 bar. The temperature range extends over -20 to +200 °C.

Benefits

  • Nominal pressure PN 400 bar as the leading rating of the device
  • Connection thread G 1/2" for direct installation in the line
  • Temperature range -20 to +200 °C for use in the workshop and in the plant
  • Version according to DIN 16270 A
  • Material 1.4571 determines strength and resistance of the part

Applications

Compressed air networks with several branches, maintenance during operation, conversions on existing plants.

Standards and conformity

The data sheets refer to DIN 16270 A. Further approvals are not documented and are therefore not stated.

Technical data

PropertyValue
Material1.4571
Versionclamping socket to clamping socket
Instrument port (female thread)G 1/2"
Pressure inletG 1/2" (female)
Test portnone
PN [bar]400
StandardDIN 16270 A
Temperature range [°C]-20 to +200
StandardsDIN 16270 A
Weight0.65 kg
ManufacturerWika
Hersteller-NrMAV 12 SMSM ES
EAN4050571480288
Zolltarifnummer84818079
GPSR HerstellerdatenA1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
AusführungSpannmuffe* - Spannmuffe*
NormDIN 16270
Temperaturbereich-20-200 °C
