2/2-way solenoid valve NC, pilot operated, media-separated, brass, G 1/2 to G 2 1/2, DN 13 to 65, 0.2 to 10 bar, FKM or NBR, 24 V DC - Riegler
With G 1/2 to G 2 1/2 ports, DN 13 to 65 and 0.2 to 10 bar, the normally closed 2/2-way solenoid valves in this series cover many switching tasks. Pilot operated, brass body, FKM or NBR seals, coil 24 V DC. Medium temperature 0 to 90 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With G 1/2 to G 2 1/2 ports, DN 13 to 65 and 0.2 to 10 bar, the normally closed 2/2-way solenoid valves in this series cover many switching tasks. Pilot operated, brass body, FKM or NBR seals, coil 24 V DC. Medium temperature 0 to 90 °C.
Benefits
- Operating pressure 0.2 to 10 bar at DN 13 to 65
- Brass body, valve seat brass and stainless steel, FKM or NBR seals
- Servo-controlled diaphragm valve that needs a minimum differential pressure, operating pressure from 0.2 bar
- Coil voltage 24 V DC, pin terminal to DIN EN 175301-803, type A, degree of protection IP 65
- Media-separated design, only the fluid body and the diaphragm are in contact with the medium
- For media from 0 to 90 °C at ambient temperatures of 0 to 55 °C
Applications
Water and neutral fluids, the brass body meets European drinking water requirements
Technical data
| Type no. | MVA.1.MS.24D.F.BV.25.MG, MVA.1.MS.24D.N.BV.25.MG, MVA.112.MS.24D.F.BV.40.MG, MVA.112.MS.24D.N.BV.40.MG, MVA.114.MS.24D.F.BV.32.MG, MVA.114.MS.24D.N.BV.32.MG, MVA.12.MS.24D.N.BV.13.MG, MVA.12.MS.24D.F.BV.13.MG, MVA.2.MS.24D.F.BV.50.MG, MVA.2.MS.24D.N.BV.50.MG, MVA.212.MS.24D.N.BV.65.MG, MVA.212.MS.24D.F.BV.65.MG, MVA.34.MS.24D.F.BV.20.MG, MVA.34.MS.24D.N.BV.20.MG |
|---|---|
| Operating pressure | 0.2 to 10 bar |
| Degree of protection | IP 65 (with connector socket fitted) |
| Electrical connection | Pin terminal to DIN EN 175301-803, type A |
| Housing | Brass |
| Valve seat | Brass and stainless steel |
| Internal parts | Brass and stainless steel |
| Ambient temperature | 0 to 55 °C |
| Medium temperature | 0 to 90 °C |
| Function | Normally closed (NC) |
| Voltage | 24 V DC |
| Seal material | FKM, NBR |
| Thread | G 1/2, G 3/4, G 1, G 1 1/4, G 1 1/2, G 2, G 2 1/2 |
| Nominal size | 13 to 65 mm |
| Dimension A | 65 to 180 mm |
| Dimension B | 123 to 185 mm |
| Dimension C | 109 to 142.5 mm |
| Manufacturer | Riegler |
| GPSR Herstellerdaten | Riegler & Co. KG, Schützenstraße 27, DE-72574 Bad Urach, www.riegler.de |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Brass |
| Housing material | Brass |
| Norm | DIN EN 175301-803, DIN EN ISO 228-1 |
| Operating voltage | 24 V DC |
| Betriebsdruck max [bar] | 10 |
| Protection rating | IP65 |
