This replacement solenoid coil works with 230 V AC and draws 28 - 29 VA. It is rated for 100 percent duty cycle and is supplied including plug or cable. The plug size is 3.
Solenoid coil, 230 V AC, coil form D, plug size 3, 28 - 29 VA, 36 x 54 x 53
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€115.36
Item
FL-069230
Manufacturer no.
MAG D 230V
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.MAG D 230V
EAN4050571475451
Customs tariff number85059029
ConditionNew
Artikel
FL-069230
Frequently Bought Together
A burnt out solenoid coil stops a whole valve even though the valve body is sound. This replacement coil works with 230 V AC and draws 28 - 29 VA. It is rated for 100 percent duty cycle and is supplied including plug or cable. The plug size is 3. The dimensions are 36 x 54 x 53.
Advantages
- Control voltage 230 V AC, matching the existing supply.
- Power consumption of 28 - 29 VA at 100 percent duty cycle.
- Plug size 3, so the existing valve plug still fits.
- Outside dimensions 36 x 54 x 53, so the space above the valve is known.
- Armature hole spacing of 51 mm, so the coil sits positively on the armature.
Technical data
| Feature | Value |
|---|---|
| Design | D |
| Control voltage | 230 V AC |
| Connector size | 3 |
| Power | 28 - 29 VA |
| External dimension [mm] | 36 x 54 x 53 |
| Distance between anchor holes L [mm] | 51 |
| Anchor holes bottom D1 [mm] | 18.3 |
| Anchor holes top D2 [mm] | 18.3 |
| Counterbore top D4 [mm] | 23.0 |
| Duty cycle | 100% duty cycle |
| Scope of delivery | Solenoid coil incl. connector or cable |
Applications
- Valves with a valve plug of size 3.
- Maintenance of plants in continuous operation.
- Keeping a spare part in the workshop store.
- Replacement of a defective coil on solenoid valves with 230 V AC.
| Weight | 0.360000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | MAG D 230V |
| EAN | 4050571475451 |
| Zolltarifnummer | 85059029 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | D |
| Power | 28 - 29 VA |
