M/49 series direct acting solenoid valve, G1/8, 3/2, NC, solenoid valve with spring return - Norgren M/49/MDZ89J

Directional valves control the air path to cylinders, grippers and actuators. The M/49 series direct acting solenoid valve Norgren M/49/MDZ89J covers the temperature range -20 to 50 °C and seals with nitrile rubber (nbr).

Benefits

• Compact installation
• Manual override as standard
• Removable encapsulated coils
• Port size G1/8
• Operating pressure 0 to 10 bar
• Flow 77 l/min

Applications

The valve is used in assembly, packaging and handling systems and in valve islands.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65 with sealed plug.
