M/49 series direct acting solenoid valve, G1/8, 3/2, NC, solenoid valve with spring return - Norgren M/49/MAZ12J
The compact body also fits tight cabinets and valve islands. The M/49 series direct acting solenoid valve Norgren M/49/MAZ12J has a body made of polyamide (pa) and seals with nitrile rubber (nbr).
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Directional valves control the air path to cylinders, grippers and actuators. The M/49 series direct acting solenoid valve Norgren M/49/MAZ12J has a body made of polyamide (pa) and is suitable for compressed air.
Benefits
- Compact installation
- Manual override as standard
- Removable encapsulated coils
- Port size G1/8
- Operating pressure 0 to 10 bar
- Flow 30 l/min
Applications
Typical uses are the control of cylinders, grippers and pneumatic tools.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65 with sealed plug.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren M/49/MAZ12J |
| Series | M/49 |
| Product line | Excel 22 |
| Valve function | 3/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Poppet |
| Mounting | Sub-base |
| Port size | G1/8 |
| Operating pressure | 0 to 10 bar |
| Flow | 30 l/min |
| Medium | Compressed air |
| Temperature range | -20 to 50 °C |
| Body material | Polyamide (PA) |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | 22 mm industrial standard |
| Operating voltage | 12 V DC |
| Power consumption | 2 W |
| Coil code | QM/48/12J/21 |
| Protection class | IP65 with sealed plug |
| Height | 74.5 mm |
| Width | 22 mm |
| Length | 45 mm |
| Weight | 0.12 kg |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | M/49/MAZ12J |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
