5/2 solenoid valve, M/1700, G 1, solenoid/solenoid, 110/120 V AC, 9380 l/min, NBR - Norgren M/1748/123/MD88J
Built for heavy duty in harsh conditions: the Norgren M/1748/123/MD88J 5/2 solenoid valve switches at the G 1 port with 9380 l/min of flow. On M/1748/123/MD88J: actuation is by double solenoid pilot, the coil runs on 110/120 V AC at 12/8 VA and the temperature range is 5 to 50 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
At the G 1 port, the Norgren M/1748/123/MD88J 5/2 solenoid valve controls compressed air across a pressure range of 2 to 10 bar. Specification of M/1748/123/MD88J: double solenoid pilot and coil for 110/120 V AC with coil code QM/48/88J/21.
Benefits
- Flow rate 9380 l/min at 2 to 10 bar
- Nitrile rubber (NBR) seals, temperature range 5 to 50 °C
- Coil for 110/120 V AC drawing 12/8 VA, connector 22 mm industry standard, IP65 protection
- Built for heavy duty in harsh environments, die-cast zinc body
- Servicing and mounting on the sub-base shorten downtime
Applications
As a 5/2 valve, Norgren M/1748/123/MD88J drives double-acting cylinders in both directions. M/1748/123/MD88J is mounted on a sub-base, the temperature range is 5 to 50 °C.
Standards and compliance
For Norgren M/1748/123/MD88J: The version is RoHS compliant, under REACH it contains no SVHC substances.
Technical data
| Manufacturer part number | M/1748/123/MD88J |
|---|---|
| Manufacturer | Norgren |
| Product type | 5/2 solenoid valve |
| Series | M/1700 |
| Valve function | 5/2 |
| Actuation | Solenoid pilot / solenoid pilot |
| Valve technology | Softseal spool |
| Spool and sleeve | Aluminium |
| Port size | G 1 |
| Operating pressure | 2 to 10 bar |
| Flow | 9380 l/min |
| Medium | Compressed air |
| Temperature range | 5 to 50 °C |
| Body material | Diecast zinc |
| Seal material | Nitrile rubber (NBR) |
| Mounting | Sub-base |
| Electrical connection | 22 mm industrial standard |
| Operating voltage | 110/120 V AC |
| Power consumption | 12/8 VA |
| Coil code | QM/48/88J/21 |
| Protection class | IP65 with sealed plug |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | subject to WEEE |
| Customs tariff number | 84812090 |
| Hersteller-Nr | M/1748/123/MD88J |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | 5/2-Wege-Magnetventil |
| Thread | G 1 |
| Housing material | Die-cast zinc |
| Function | 5/2 bistable |
| Actuation type | Electrical |
| Betriebsdruck max [bar] | 10 |
| Protection rating | IP65 |
