Solenoid valve 5/2 monostable, G 1, 220/240 V AC, 9380 l/min, M/1700 series - Norgren M/1748/172/MD89J
With 9380 l/min flow with G 1 ports, the Norgren M/1748/172/MD89J covers the 5/2 monostable function across 2.7 to 10 bar. The M/1748/172/MD89J is driven with 220/240 V AC at 12/8 VA via a 22 mm industrial standard connection.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Norgren M/1748/172/MD89J is a M/1700 series solenoid valve for 5/2 monostable with G 1 ports, rated for 2.7 to 10 bar and 9380 l/min flow. The QM/48/89J/21 coil of the M/1748/172/MD89J runs on 220/240 V AC at 12/8 VA, protection class IP65 with sealed plug. The M/1748/172/MD89J uses a soft-seal spool design with a diecast zinc body.
Benefits
- Flow 9380 l/min at 2.7 to 10 bar operating pressure
- Coil QM/48/89J/21 for 220/240 V AC, 12/8 VA
- Electrical connection 22 mm industrial standard, protection class IP65 with sealed plug
- Temperature range 5 to 50 °C
Applications
Through its G 1 ports the M/1748/172/MD89J supplies cylinders and actuators with compressed air within 2.7 to 10 bar.
Standards and compliance
The M/1748/172/MD89J is RoHS compliant, contains no SVHC substances under REACH and is covered by the WEEE directive.
Technical data
| Product type | Solenoid valve |
|---|---|
| Series | M/1700 |
| Valve function | 5/2 |
| Actuation | Solenoid pilot / spring and air spring return |
| Valve technology | Soft-seal spool |
| Spool and sleeve | Aluminium |
| Port size | G 1 |
| Operating pressure | 2.7 to 10 bar |
| Flow | 9380 l/min |
| Medium | Compressed air |
| Temperature range | 5 to 50 °C |
| Body material | Diecast zinc |
| Seal material | Nitrile rubber (NBR) |
| Mounting | Sub-base |
| Electrical connection | 22 mm industrial standard |
| Operating voltage | 220/240 V AC |
| Power consumption | 12/8 VA |
| Coil code | QM/48/89J/21 |
| Protection class | IP65 with sealed plug |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer part number | M/1748/172/MD89J |
| Manufacturer | Norgren |
| Hersteller-Nr | M/1748/172/MD89J |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1 |
| Housing material | Die-cast zinc |
| Function | 5/2 monostable |
| Actuation type | Electrical |
| Betriebsdruck max [bar] | 10 |
| Protection rating | IP65 |
