Solenoid valve 5/3 centre open to exhaust, G 1/4, 110/120 V AC, 1290 l/min, M/1700 series - Norgren M/1772/6123/MA18J
Norgren M/1772/6123/MA18J is a M/1700 series solenoid valve for 5/3 centre open to exhaust with G 1/4 ports, rated for 3 to 10 bar and 1290 l/min flow. The M/1772/6123/MA18J uses coil QM/48/18J/21 for 110/120 V AC at 4/2.5 VA with protection class IP65 with sealed plug.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren M/1772/6123/MA18J M/1700 series solenoid valve provides the 5/3 centre open to exhaust function with G 1/4 ports and reaches 1290 l/min flow at 3 to 10 bar. The M/1772/6123/MA18J is driven with 110/120 V AC at 4/2.5 VA via a 22 mm industrial standard connection. The M/1772/6123/MA18J uses a soft-seal spool design with a diecast zinc body.
Benefits
- Flow 1290 l/min at 3 to 10 bar operating pressure
- Coil QM/48/18J/21 for 110/120 V AC, 4/2.5 VA
- Electrical connection 22 mm industrial standard, protection class IP65 with sealed plug
- Temperature range 5 to 50 °C
Applications
Through its G 1/4 ports the M/1772/6123/MA18J supplies cylinders and actuators with compressed air within 3 to 10 bar.
Standards and compliance
The M/1772/6123/MA18J is RoHS compliant, contains no SVHC substances under REACH and is covered by the WEEE directive.
Technical data
| Product type | Solenoid valve |
|---|---|
| Series | M/1700 |
| Valve function | 5/3 |
| Function | COE (centre open to exhaust) |
| Actuation | Solenoid pilot / solenoid pilot |
| Valve technology | Soft-seal spool |
| Spool and sleeve | Aluminium |
| Port size | G 1/4 |
| Operating pressure | 3 to 10 bar |
| Flow | 1290 l/min |
| Medium | Compressed air |
| Temperature range | 5 to 50 °C |
| Body material | Diecast zinc |
| Seal material | Nitrile rubber (NBR) |
| Mounting | Sub-base |
| Electrical connection | 22 mm industrial standard |
| Operating voltage | 110/120 V AC |
| Power consumption | 4/2.5 VA |
| Coil code | QM/48/18J/21 |
| Protection class | IP65 with sealed plug |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer part number | M/1772/6123/MA18J |
| Manufacturer | Norgren |
| Hersteller-Nr | M/1772/6123/MA18J |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/4 |
| Housing material | Die-cast zinc |
| Actuation type | Electrical |
| Betriebsdruck max [bar] | 10 |
| Protection rating | IP65 |
