Sub-base valve M/1700 G1/4, 5/3 centre position all ports blocked, without coil - Norgren QM/1762/6123/MD/11

Norgren ✓ Original product Brand new

Holds cylinders in any intermediate position, as the Norgren sub-base valve M/1700 QM/1762/6123/MD/11 blocks all ports in centre position and delivers 1290 l/min flow at 2.7 to 10 bar. The QM/1762/6123/MD/11 mounts on a sub-base, the solenoid coil is not included and is selected to suit the control voltage.

Net
€2,210.40
excl. VAT
Item NRG-QM/1762/6123/MD/11
Manufacturer no. QM/1762/6123/MD/11
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren sub-base valve M/1700 QM/1762/6123/MD/11 with port size G1/4 switches compressed air as a 5/3-way valve, centre position all ports blocked, at 2.7 to 10 bar. Flow of the QM/1762/6123/MD/11 is 1290 l/min, the body is made of die-cast zinc.

Benefits

  • Flow 1290 l/min at an operating pressure of 2.7 to 10 bar
  • Soft-seal spool made of aluminium with nitrile rubber (NBR) seals
  • Centre position all ports blocked, the cylinder stays pressurised in an intermediate position
  • Replacement on the sub-base without disconnecting the piping
  • Temperature range 5 to 50 °C

Applications

The M/1700 series is designed for heavy duty, the QM/1762/6123/MD/11 controls cylinders in presses, woodworking machinery and steel plants with compressed air at 2.7 to 10 bar.

Standards and conformity

The QM/1762/6123/MD/11 is RoHS compliant and contains no SVHC substances under REACH.

Technical data

ManufacturerNorgren
Part numberQM/1762/6123/MD/11
SeriesM/1700
Valve function5/3
Switching modecentre position all ports blocked
Actuationsolenoid pilot / solenoid pilot
Valve technologysoft-seal spool
Spool and sleevealuminium
Port sizeG1/4
Operating pressure2.7 to 10 bar
Flow1290 l/min
Mediumcompressed air
Temperature range5 to 50 °C
Body materialdie-cast zinc
Seal materialnitrile rubber (NBR)
Mountingsub-base
Electrical connectionwithout solenoid coil
Country of originGermany
RoHScompliant
REACHno SVHC substances
WEEEnot subject to WEEE
Customs tariff number84812090
Hersteller-NrQM/1762/6123/MD/11
Zolltarifnummer84812090
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Ausführungohne Magnetspule
Housing materialDie-cast zinc
Function5/3 mid-position closed
DesignPiston pusher
Actuation typeElectrical
Betriebsdruck max [bar]10
Pneumatic connectionG1/4
Temperature (max.)50
