Solenoid valve 5/3 all ports blocked, G 1/4, 24 V DC, 1290 l/min, M/1700 series - Norgren M/1762/6123/MA13J

Norgren ✓ Original product Brand new

The Norgren M/1762/6123/MA13J M/1700 series solenoid valve provides the 5/3 all ports blocked function with G 1/4 ports and reaches 1290 l/min flow at 2.7 to 10 bar. The QM/48/13J/21 coil of the M/1762/6123/MA13J runs on 24 V DC at 2 W, protection class IP65 with sealed plug.

Net
€2,219.05
excl. VAT
Item NRG-M/1762/6123/MA13J
Manufacturer no. M/1762/6123/MA13J
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With 1290 l/min flow with G 1/4 ports, the Norgren M/1762/6123/MA13J covers the 5/3 all ports blocked function across 2.7 to 10 bar. The M/1762/6123/MA13J uses coil QM/48/13J/21 for 24 V DC at 2 W with protection class IP65 with sealed plug. The M/1762/6123/MA13J uses a soft-seal spool design with a diecast zinc body.

Benefits

  • Flow 1290 l/min at 2.7 to 10 bar operating pressure
  • Coil QM/48/13J/21 for 24 V DC, 2 W
  • Electrical connection 22 mm industrial standard, protection class IP65 with sealed plug
  • Temperature range 5 to 50 °C

Applications

Through its G 1/4 ports the M/1762/6123/MA13J supplies cylinders and actuators with compressed air within 2.7 to 10 bar.

Standards and compliance

The M/1762/6123/MA13J is RoHS compliant, contains no SVHC substances under REACH and is covered by the WEEE directive.

Technical data

Product typeSolenoid valve
SeriesM/1700
Valve function5/3
FunctionAPB (all ports blocked)
ActuationSolenoid pilot / solenoid pilot
Valve technologySoft-seal spool
Spool and sleeveAluminium
Port sizeG 1/4
Operating pressure2.7 to 10 bar
Flow1290 l/min
MediumCompressed air
Temperature range5 to 50 °C
Body materialDiecast zinc
Seal materialNitrile rubber (NBR)
MountingSub-base
Electrical connection22 mm industrial standard
Operating voltage24 V DC
Power consumption2 W
Coil codeQM/48/13J/21
Protection classIP65 with sealed plug
RoHSCompliant
REACHSVHC substance not present
WEEEWEEE
Manufacturer part numberM/1762/6123/MA13J
ManufacturerNorgren
Hersteller-NrM/1762/6123/MA13J
Zolltarifnummer84812090
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/4
Housing materialDie-cast zinc
Actuation typeElectrical
Betriebsdruck max [bar]10
Protection ratingIP65
