Sub-base valve M/1700 G1/2, 5/3 centre position open to exhaust, 24 V DC - Norgren M/1774/6123/MA13J
Leaves cylinders unpressurised in centre position, as the Norgren sub-base valve M/1700 M/1774/6123/MA13J vents both working ports there and delivers 3200 l/min flow at 2.7 to 10 bar. The M/1774/6123/MA13J mounts on a sub-base, its coil QM/48/13J/21 runs on 24 V DC at 2 W.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren sub-base valve M/1700 M/1774/6123/MA13J with port size G1/2 switches compressed air as a 5/3-way valve, centre position open to exhaust, at 2.7 to 10 bar. Flow of the M/1774/6123/MA13J is 3200 l/min, the body is made of die-cast zinc.
Benefits
- Flow 3200 l/min at an operating pressure of 2.7 to 10 bar
- Soft-seal spool made of aluminium with nitrile rubber (NBR) seals
- Centre position open to exhaust, both cylinder ports are vented
- Replacement on the sub-base without disconnecting the piping
- Coil QM/48/13J/21 with 24 V DC and 2 W
- Temperature range 5 to 50 °C, protection class IP65 with sealed connector
Applications
The M/1700 series is designed for heavy duty, the M/1774/6123/MA13J controls cylinders in presses, woodworking machinery and steel plants with compressed air at 2.7 to 10 bar.
Standards and conformity
The M/1774/6123/MA13J is RoHS compliant and contains no SVHC substances under REACH.
Technical data
| Manufacturer | Norgren |
|---|---|
| Part number | M/1774/6123/MA13J |
| Series | M/1700 |
| Valve function | 5/3 |
| Switching mode | centre position open to exhaust |
| Actuation | solenoid pilot / solenoid pilot |
| Valve technology | soft-seal spool |
| Spool and sleeve | aluminium |
| Port size | G1/2 |
| Operating pressure | 2.7 to 10 bar |
| Flow | 3200 l/min |
| Medium | compressed air |
| Temperature range | 5 to 50 °C |
| Body material | die-cast zinc |
| Seal material | nitrile rubber (NBR) |
| Mounting | sub-base |
| Electrical connection | 22 mm industrial standard |
| Operating voltage | 24 V DC |
| Power consumption | 2 W |
| Coil code | QM/48/13J/21 |
| Protection class | IP65 with sealed connector |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | no SVHC substances |
| WEEE | subject to WEEE |
| Customs tariff number | 84812090 |
| Hersteller-Nr | M/1774/6123/MA13J |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Housing material | Die-cast zinc |
| Function | 5/3 mid-position exhausted |
| Flow rate [l/min] | 3200 |
| Design | Piston pusher |
| Actuation type | Electrical |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | G1/2 |
| Protection rating | IP65 |
| Temperature (max.) | 50 |
